uProcess Automated 4-port Cross Valve AV2X2

Two-position, four-port automated valve for interface with 1/16” OD tubing (AV2X2-T116).

The AV2X2 cross valve is part of LabSmith’s uProcess platform, which simplifies construction and control of microfluidic systems. Automated uProcess components include syringe pumps, temperature and pressure sensors, selector valves, temperature controllers and more. Microsoft Windows®-based uProcess software provides straightforward control of all devices. Use uProcess to generate automated scripts to control both simple setups or complex lab automation.

LabSmith’s AV2X2 valves are constructed with Vespel® as the wetted material*, for use with a wide variety of chemicals.

Requires a 4VM02 valve manifold and EIB200 interface controller for communicating with PC. Connects to capillary via CapTite one-piece fittings (not included).

* Selected valves are available with PCTFE Kel-F® as the wetted material. Contact LabSmith for pricing and availability.

Microfluidic Valve - uProcess automated 4-port cross valve AV2X2

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 132.

Fluidic interface: Mini Luer.

Material: PMMA.

Description: Rhombic chamber chip eP2.

Chamber dimensions: 6 ml volume, 200 mm deep.

Fluidic 132, reaction chamber chip, rhombic chamber chip eP2, 10001821, microfluidic chipshop

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 1196.

Fluidic interface: Through Hole.

Material: Glass.

Description: Multi-channel design, single cross geometry; channel depth (nozzle): 200 µm.



Fluidic 1196, droplet generator chip, 10001547, microfluidic chipshop

Cell Culture Chip

Type: Cell Culture Chip.

Design: Fluidic 992.

Fluidic Interface: Mini Luer.

Material: Zeonor.

Description: Chamber chip with pre-heating channel.

Dimensions: Chamber volume: 30 ul; Ground surface: 100 mm2.

Fluidic 992, cell culture chip,10001343, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 268.

Fluidic interface: Luer.

Material: Zeonor.

Description: Straight channel chip with 1 channel, with double-sided adhesive tape.

Channel dimensions: 2500 µm wide x 150 µm deep x 58.5 mm long.

fluidic 268, straight channel, 10001136, microfluidic chipshop

Chip Lid

Type: Chip lid.

Material: Topas.

Description: Chip lid for microtiter plate sized devices.

Pack of 10.

fluidic 854, chip lid,10001087,microfluidic chipshop

Interaction Chip

Type: Interaction.

Design: Fluidic 737.

Fluidic interface: Mini Luer.

Material: PS.

Chamber dimensions: 53.1 ml volume, 600 mm deep.

Fluidic 737,interaction chip, 10001061, microfluidic chipshop

Interaction Chip

Type: Interaction.

Design: Fluidic 688.

Fluidic interface: Mini Luer.

Material: PS.

Chamber dimensions: 37.8 ml volume, 400 mm deep.

Fluidic 688,interaction chip, 10001056, microfluidic chipshop

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 842.

Fluidic interface: Mini Luer.

Material: Zeonor.

Chamber dimensions: 50 mL volume, 500 mm deep.

Fluidic 842,reaction chamber chip,10001033, microfluidic chipshop

Droplet Generation Chip

Type: Droplet Generator.

Design: Fluidic 719.

Fluidic interface: Mini Luer.

Material: PC.

Description: Droplet generation and storage chip.

Fluidic 719, droplet generation chip, 10000752, microfluidic chipshop

PCR Chip

Type: PCR.

Design: Fluidic 708.

Material: Topas.

Interface: Olive.

Description: PCR chip with meandering channels for continuous flow.

Channel dimensions: 200 mm wide x 100 mm deep x 1879 mm length.

Notes: 41 cycles (1 inlet, 1 outlet).

Fluidic 708, reaction chip, 10000745, microfluidic chipshop

PCR Chip

Type: PCR

Design: Fluidic 708.

Material: PC.

Interface: Olive.

Description: PCR chip with meandering channels for continuous flow.

Channel dimensions: 200 mm wide x 100 mm deep x 1879 mm length.

Notes: 41 cycles (1 inlet, 1 outlet).

Fluidic 708, reaction chip, 10000745, microfluidic chipshop

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 584.

Fluidic interface: Mini Luer.

Material: Topas.

Description: Reaction chamber chip.

Chamber dimensions: 20 µL volume, 500 µm deep.

Fluidic 584, reaction chamber chip,10000554, microfluidic_chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 558.

Fluidic interface: Mini Luer.

Material: Zeonor.

Description: Straight-channel chip with 16 parallel channels.

Channel dimensions: 10 µm wide x 700 µm deep x 18 mm long.

Fluidic 558, straight channel chip, 10000543,, microfluidic chipshop

Assay Chip

Type: Assay Chip.

Design: Fluidic 429.

Fluidic Interface: Mini Luer.

Material: Topas.

Description: Assay Chip 1, on-board metering, mixing, and reaction; two turning valves included.

Dimensions:

  • Metering cavity volume: 15 µl
  • Metering loop volume; 17 µl
  • Mixing chamber volume: 102 µl
  • Reaction & detection chamber volume: 20 µl
Fluidic 429, assay chip 1, 10000373, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 144.

Fluidic interface: Through Hole.

Material: PMMA.

Description: Straight-channel chip with 4 parallel channels.

Channel dimensions: 100 µm wide x 100 µm deep x 58.5 mm long.

Fluidic 144, straight channel chip, 10000193, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 142.

Fluidic interface: Through Hole.

Material: Topas.

Description: Straight-channel chip with 16 channels.

Channel dimensions: 200 µm wide x 100 µm deep x 18 mm long.

Fluidic 142, straight channel chip, 10000195, 10000196, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 142.

Fluidic interface: Through Hole.

Material: PMMA.

Description: Straight-channel chip with 16 channels.

Channel dimensions: 200 µm wide x 100 µm deep x 18 mm long.

Fluidic 142, straight channel chip, 10000195, 10000196, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 144.

Fluidic interface: Through Hole.

Material: Topas.

Description: Straight-channel chip with 4 parallel channels.

Channel dimensions: 100 µm wide x 100 µm deep x 58.5 mm long.

Fluidic 144, straight channel chip, 10000193, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 144.

Fluidic interface: Through Hole.

Material: PMMA.

Description: Straight-channel chip with 4 parallel channels.

Channel dimensions: 100 µm wide x 100 µm deep x 58.5 mm long.

Fluidic 144, straight channel chip, 10000193, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 138.

Fluidic interface: Through Hole.

Material: Topas.

Description: Straight-channel chip with 4 parallel channels.

Channel dimensions: 1000 µm wide x 200 µm deep x 58.5 mm long.

Fluidic 138, straight channel chip, 10000188, microfluidic chip, microfluidic chipshop

Turning Valve Test Chip

Type: Turning Valve.

Design: Fluidic 155.

Fluidic Interface: Mini Luer.

Material: Zeonor.

Description: turning valve chip. Two turning valves included.

fluidic 155,turning valve test chip, 10000183, microfluidic chipshop

Cell Sorting Chip

Type: Sorting Chip.

Design: Fluidic 381.

Fluidic interface: Mini Luer.

Material: Zeonor.

Description: Particle and Cell Sorting Chip - Sheath Flow.

Channel Dimensions: Channel depth structure 1: 30 um; Channel depth structure 2: 30 um.



Fluidic 381, 10001823, 10000128, particle and cell sorting chip, microfluidic ChipShop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 152.

Fluidic interface: Mini Luer.

Material: Topas.

Description: Straight-channel chip with 16 parallel channels.

Channel dimensions: 1000 µm wide x 200 µm deep x 18 mm long.

Straight 16-channel Through Hole Chip, Fluidic 152, 10000198 - Microfluidic ChipShop

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 163.

Fluidic interface: Mini Luer.

Material: PC.

Description: One channel design; input channel width: 140 µm; collection channel width: 420 µm; channel depth: 140 µm.

Droplet Generator Chip 10000006 , Mini-Luer, Topas,  13-1003-0163-02 Microfluidic ChipShop

Stand-alone Olive Fluidic Interface

Type: Fluid Connector Single.

Design: Fluidic 630.

Chip interface: Olive.

Material: Opaque PP.

Quantity per pack: 10.

Fluidic 630, stand-alone olive fluid connector, 10000700, microfluidic chipshop

Handling Frame

Type: Frame.

Fluidic: 352.

Description: These stackable handling frames allow you to use all your standard equipment that can handle devices with the well spacing of a 1536 microtiter plate, for example for pipetting and read out of your microfluidic chips.

Details: Orange, high skirt.



fluidic 352 handling frame orange 10000043, microfluidic chipshop

Mini Luer Plug – Red

Type: Plug.

Design: Fluidic 793.

Chip interface: Mini Luer.

Material: PP.

Color: Red.

Description: Single, one-wing, low volume displacement.

Quantity: 10.

One-wing Mini Luer Male Plug Low Volume Displacement, 10001068, Microfluidic ChipShop

PCR Chip

Type: PCR.

Design: Fluidic 243.

Fluidic interface: Olive.

Material: PC.

Chip with meandering channels for continuous flow PCR.

Channel dimensions: 600 mm wide x 300 mm deep x 1637 mm length.

Notes: 40 cycles (1 inlet, 1 outlet).



Microfluidic Chip - Meander and Continuous Flow PCR Chip, Olive, Zeonor, 10000011, Microfluidic ChipShop

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 166.

Fluidic interface: Through Hole.

Material: PMMA.

Cross channel chip with two perpendicular channels.

Through hole diameter: 1 mm.

Channel dimensions: 100 µm wide x 100 µm deep x 87 mm long.

Lid Thickness: 175 µm.



Herringbone Mixer Chip

Type: Micro Mixer.

Design: Fluidic 1460.

Fluidic interface: Mini Luer.

Material: Zeonor.

Micro Mixer - Herringbone Mixer.

Micro Mixer - herringbone mixer, fluidic 1460, 10001930, microfluidic ChipShop

Tank with Luer Interface

Type: Tank.

Design: Fluidic 639.

Chip Interface: Luer.

Material: PP.

Description: Single, 500 µl volume, cap with Mini Luer interface (with venting membrane in cap).

Quantity: 10 single tanks.

Microfluidic Tanks 500 ul Luer Interface with Cap Mini Luer Interface 10000761  16-0618-0639-09 Microfluidic ChipShop

Through Hole Connector

Type: Fluid Connector.

Design: Fluidic 302.

Chip interface: Through Hole.

Fluid interface: Luer Lock.

Material: Topas.

Quantity per pack: 10.

Notes: 1.3 mm diameter through hole size.

Female Luer Lock Compatible Connector 10000227, Microfluidic ChipShop

Mini Luer Fluid Connector – Red

Type: Fluid Connector - Single.

Design: Fluidic 331.

Chip interface: Mini Luer.

Fluid interface: Male.

Material: Red PP.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Quantity per pack: 10.



Male mini-Luer fluid connector, 10000094, 10000096, 10000029, 10000116, microfluidic ChipShop

Straight Channel Chip – Open Platform

Type: Straight Channel.

Design: Fluidic 268.

Fluidic interface: Luer.

Material: Topas.

Straight-channel Chip with 1 Channel.  Open Platform Chip for Self-assembly.

Channel dimensions: 2500 µm wide x 290 um deep x 58.5 mm long.

Straight Channel Chip, open platform, 10000306, Fluidic 268, Luer, Topas, microfluidic ChipShop

Cell Sorting Chip

Type: Sorting Chip.

Design: Fluidic 381.

Fluidic interface: Mini Luer.

Material: PMMA.

Details: Particle and Cell Sorting Chip - Sheath Flow

Fluidic 381, 10001823, 10000128, particle and cell sorting chip, microfluidic ChipShop

Assay Development Chip

Type: Assay Development.

Design: Fluidic 490.

Fluidic Interface: Mini Luer.

Material: Topas.

Description: Assay development chip for magnetic bead based or hybridization assays; two turning valves included.

Cavity Volume: 30 µl.

Fluidic 490, 10000375, assay development chip, microfluidic ChipShop

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 561.

Fluidic interface: Mini Luer.

Material: Zeonor.

Chamber Dimensions: 10 mL volume, 350 mm deep.

Lid thickness: 188 mm.

Reaction chamber chip, Mini Luer, Zeonor, Fluidic 561, microfluidic ChipShop,

Membrane Chip

Type: Membrane.

Design: Fluidic 783.

Fluidic interface: Mini Luer.

Material: Topas.

Membrane Chip with 2 Plasma Generation Units.



fluiidic 783, membrane chip, plasma generation chip, 10000981, microfluidic chipshop

Finger Pump Mixer

Type: Micro Mixer.

Design: Fluidic 999.

Fluidic interface: Mini Luer.

Material: Zeonor.

Description: Micro mixer, finger pump mixer chip.

Lid thickness: 140 µm.

fluidic 999, micro mixer, finger pump mixer, fingerpump mixer, microfluidic chipshop

Serpentine Mixer Chip

Type: Micro Mixer.

Design: Fluidic 1079.

Fluidic interface: Mini Luer.

Material: Zeonor.

Micro Mixer - 3D Serpentine Mixer.

Lid thickness: 188 µm.

Micro Mixer - 3d serpentine mixer, fluidic 1079, 10001477, microfluidic ChipShop

Snowman Mixer Chip

Type: Micro Mixer.

Design: Fluidic 1108.

Fluidic interface: Mini Luer.

Material: Topas.

Description: Micro Mixer - Snowman Mixer.

Lid thickness: 140 µm.

Micro Mixer - snowman mixer, fluidic 1108, 10001502, microfluidic ChipShop

Herringbone Mixer Chip

Type: Micro Mixer.

Design: Fluidic 1460.

Fluidic interface: Mini Luer.

Material: PC.

Micro Mixer - Herringbone Mixer.

Micro Mixer - herringbone mixer, fluidic 1460, 10001930, microfluidic ChipShop

Adhesive Ring

Type: Adhesive ring for Fluidic 302 (Female Luer Lock Compatible Interface).

Design: Fluidic 697.

Adhesive Ring, Fluidic 697, for Female Luer Lok Compatible Interface, microfluidic ChipShop

PCR Chip

Type: PCR.

Design: Fluidic 683.

Fluidic interface: Mini Luer.

Material: Topas.

PCR Chip with dead-end air reservoir.

Chamber dimensions: 10 chambers, 10 ml volume, 500 mm deep.

Lid thickness: 175 mm.

fluidic 683, PCR Chip, mini luer, Topas, 10000786, microfluidic ChipShop

Membrane Chip

Type: Membrane.

Design: Fluidic 200.

Fluidic interface: Luer and Mini Luer.

Material: Topas.

Plasma/Serum Generation Chip with 4 Plasma Generation Membranes.

Membrane Diameter: 10 mm.



fluiidic 200, membrane chip, plasma serum generation chip, 10000021, microfluidic chipshop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 152.

Fluidic interface: Through Hole.

Material: Topas.

Description: Straight-channel chip with 16 parallel channels.

Channel dimensions: 1000 µm wide x 200 µm deep x 18 mm long.

Lid Thickness: 140 µm.

Straight 16-channel Through Hole Chip, Fluidic 152, 10000198 - Microfluidic ChipShop

AV Motor Kit

Replacement motor kit for AV series automated valves.
Includes motor with PCB and installed fork.

Manual Turning Valve Actuator

Manual turning valve actuator for microfluidic ChipShop rotary valve.  Tool only—chip not included.

Quantity per pack: 1.

10000742 turning valve actuator

Mini Luer Cap

Type: Plug.

Design: Fluidic 1262.

Chip interface: Mini Luer.

Material: Green TPE.

Quantity per set: 10.

Description: Mini Luer cover for preventing evaporation and contamination.

Mini Luer Cap - Single, 10001686, fluidic 1262, microfluidic chipshop

Cell Sorting Chip

Type: Sorting Chip

Design: Fluidic 386.

Fluidic interface: Mini Luer.

Material: PMMA.

Details: Particle and Cell Sorting Chip - Sheath Flow

Fluidic 386, 10000158, 10001824, particle and cell sorting chip, microfluidic ChipShop

Cell Sorting Chip

Type: Sorting Chip

Design: Fluidic 386.

Fluidic interface: Mini Luer.

Material: Zeonor.

Details: Particle and Cell Sorting Chip - Sheath Flow

Fluidic 386, 10000158, particle and cell sorting chip, microfluidic ChipShop

Adhesive Ring

Type: Other.

Design: Fluidic 699.

Chip interface: Through Hole.

Fluidic interface: Olive

Material: Opaque PMMA.

Quantity per pack: 10.

Cross-channel Chip with Electrodes

Type: Cross Channel Electrode Chip.

Design: Fluidic 201.

Fluidic interface: Through Hole.

Material: PMMA.

Cross channel chip with two perpendicular channels. Note: 1 mm through hole size.

Channel dimensions: 50 mm wide x 50 mm deep x 87.8 mm long.

Lid Thickness: 175 mm.

Mini Luer Plug

Type: Plug.

Design: Fluidic 334.

Chip interface: Mini Luer.

Material: Red PP

Description: Single.

Quantity per pack: 10.



Mini Luer Plug - Single, 10000053, fluidic 334, microfluidic chipshop

H-shaped Channel Chip

Type: H-shaped Channel.

Design: Fluidic 164.

Fluidic interface: Mini Luer.

Material: PMMA.

Chip with 4 sets of H-shaped channels.

Channel dimensions:

Channel I Channel II Channel III Channel IV
Inlet & outlet width 75 µm 75 µm 150 µm 150 µm
Middle width 75 µm 150 µm 150 µm 300 µm



Microfluidic Chip - H-shaped Channel Mini-Luer Chip, 10000265

Membrane Chip

Type: Membrane.

Design: Fluidic 480.

Fluidic interface: Mini luer.

Material: PS.

Cross flow membrane chip with 2 transparent Membranes

Pore size: .4 mm.



Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 1003.

Fluidic interface: Mini Luer.

Material: PC.

Chamber dimensions: 27 mL volume, 350 mm deep.

Lid thickness: 188 mm.

Reaction chamber chip, Microfluidic ChipShop, Mini Luer, Zeonor,  Fluidic 1003

Diffusion Mixer Chip

Type: Micro Mixer.

Design: Fluidic 186.

Fluidic interface: Luer.

Material: PC.

Diffusion Mixer Chip

Channel depth: 100 µm.

Channel width inlets: 100/200 µm.

Channel width mixer: 200 µm.

Channel width outlet: 200 µm.

Lid thickness: 175 µm.

fluidic 186, micro mixer, microfluidic chipshop

Pearl Chain Mixer Chip

Type: Micro Mixer.

Design: Fluidic 658.

Fluidic interface: Mini Luer.

Material: Topas.

Micro Mixer - pearl chain mixer.

Lid thickness: 125 µm.

Micro Mixer - Pearl Chain Mixer, P/N 10000759, microfluidic ChipShop

Cell Sorting Chip

Type: Sorting Chip

Design: Fluidic 283.

Fluidic interface: Mini Luer.

Material: Zeonor.

Details: Particle and Cell Sorting Chip - Sheath Flow

Fluidic 283, Microfluidic ChipShop

Cell Sorting Chip

Type: Sorting Chip

Design: Fluidic 283.

Fluidic interface: Mini Luer.

Material: PMMA.

Details: Particle and Cell Sorting Chip - Sheath Flow

Fluidic 283, Microfluidic ChipShop

Handling Frame

Type: Frame.

Description: These stackable handling frames allow you to use all your standard equipment that can handle devices with the well spacing of a 1536 microtiter plate, for example for pipetting and read out of your microfluidic chips.

Fluidic: 353

Description: Orange, low skirt

Handling Frame for microfluidic chips, 10000041, Microfluidic ChipShop

Handling Frame

Type: Frame.

Description: These stackable handling frames allow you to use all your standard equipment that can handle devices with the well spacing of a 1536 microtiter plate, for example for pipetting and read out of your microfluidic chips.

Fluidic: 352

Details: Yellow, high skirt

Handling Frame for microfluidic chips, 10000042, Microfluidic ChipShop

Handling Frame

Type: Frame.

Description: These stackable handling frames allow you to use all your standard equipment that can handle devices with the well spacing of a 1536 microtiter plate, for example for pipetting and read out of your microfluidic chips.

Fluidic: 352

Description: Red, high skirt

Handling Frame for microfluidic chips, 10000044, Microfluidic ChipShop

Mini Luer Plug – Red

Type: Plug.

Design: Fluidic 438.

Chip interface: Mini Luer.

Material: Red PP.

Quantity: 10.

Description: Single, low volume displacement Mini Luer plug.

Mini-Luer Male Plug, Low Volume Displacement 10000205, 10000280, Microfluidic ChipShop

Mini Luer Plug – Opaque

Type: Plug.

Design: Fluidic 438.

Chip interface: Mini Luer.

Material: Opaque TPE.

Quantity: 10.

Description: Single, low volume displacement Mini Luer plug.

Mini-Luer Male Plug, Low Volume Displacement 10000205, 10000280, Microfluidic ChipShop

Microscope Slides

Type: Microscope Slides.

Description: 75.5 mm x 25.5 mm x 1.0 mm thick individually wrapped microscopy slides.

Quantity: 10.

Material: Black Zeonor.







Microscope slides, Microfluidic ChipShop, PMMA, Zeonor

Microscope Slides

Type: Microscope Slides.

Description: 75.5 mm x 25.5 mm x 1.0 mm thick individually wrapped microscopy slides.

Quantity: 10.

Material: Zeonor.







Microscope slides, Microfluidic ChipShop, PMMA, Zeonor

Microscope Slides

Type: Microscope Slides.

Description: 75.5 mm x 25.5 mm x 1.0 mm thick individually wrapped microscopy slides.

Quantity: 10.

Material:  Black PMMA.







Microscope slides, Microfluidic ChipShop, PMMA, Zeonor

Microscope Slides

Type: Microscope Slides.

Description: 75.5 mm x 25.5 mm x 1.0 mm thick individually wrapped microscopy slides.

Quantity: 10.

Material:  PMMA.







Microscope slides, Microfluidic ChipShop, PMMA, Zeonor

Mini Luer Fluid Connector – Opaque

Type: Fluid Connector - Single.

Design: Fluidic 331.

Chip interface: Mini Luer.

Fluid interface: Male.

Material: TPE.

Color: Opaque.

Quantity per pack: 10.

Note: TPE is softer, for easy closing of fluidic interfaces with minimal force. PP is a harder material that is easy to use for interfacing with tubing.

Male mini-Luer fluid connector, 10000094, 10000096, 10000029, 10000116, microfluidic ChipShop

Mini Luer Fluid Connector – Green

Type: Fluid Connector - Single.

Design: Fluidic 331.

Chip interface: Mini Luer.

Fluid interface: Male.

Material: Green PP.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Quantity per pack: 10.

Male mini-Luer fluid connector, 10000094, 10000096, 10000029, 10000116, microfluidic ChipShop

Mini Luer Fluid Connector – Opaque

Type: Fluid Connector - Single.

Design: Fluidic 331.

Chip interface: Mini Luer.

Fluid interface: Male.

Material: Opaque PP.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Quantity per pack: 10.



Male mini-Luer fluid connector, 10000094, 10000096, 10000029, 10000116, microfluidic ChipShop

Mini Luer Fluid Connector – Blue

Type: Fluid Connector - Single.

Design: Fluidic 331.

Chip interface: Mini Luer.

Fluid interface: Male.

Material: Blue PP.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Quantity per pack: 10.

Male mini-Luer fluid connector, 10000094, 10000096, 10000029, 10000116, microfluidic ChipShop

Luer Plug – Opaque

Type: Plug.

Design: Fluidic 270.

Chip interface: Luer.

Description: Single.

Quantity: 10.

Material: Opaque PMMA.



Male Luer Plug, 10000230, 10000231, Microfluidic ChipShop

Luer Plug – Black

Type: Plug.

Design: Fluidic 270.

Chip interface: Luer.

Description: Single.

Quantity: 10.

Material: Black PP.



Male Luer Plug, 10000230, 10000231, Microfluidic ChipShop

Luer Fluid Connector – Green

Type: Fluid Connector - Single.

Design: Fluidic 263.

Chip interface: Luer.

Fluid interface: Male.

Material: Green PP.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Quantity per pack: 10.

Male Luer Fluid Connector, 10000080, 10000081, Microfluidic ChipShop

Luer Fluid Connector – Opaque

Type: Fluid Connector - Single.

Design: Fluidic 263.

Chip interface: Luer.

Fluid interface: Male.

Material: Opaque PP.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Quantity per pack: 10.

Male Luer Fluid Connector, 10000080, 10000081, Microfluidic ChipShop

Mini Luer Plug

Type: Plug.

Design: Fluidic 334.

Chip interface: Mini Luer.

Material: Green PP

Description: Single.

Quantity: 10.

Mini Luer Male Plug, PP, TPE, 10000030,10000052, 10000054, 09-0559-0334-09, 09-0559-0334-11

Mini Luer Plug

Type: Plug.

Design: Fluidic 334.

Chip interface: Mini Luer.

Material: Green PP

Description: Single.

Quantity: 10.



Mini Luer Plug - Single, 10000052, fluidic 334, microfluidic chipshop

Mini Luer Plug

Type: Plug.

Design: Fluidic 334.

Chip interface: Mini Luer.

Material: Opaque TPE

Description: Single.

Quantity: 10.



Mini Luer Male Plug, PP, TPE, 10000030,10000052, 10000054, 09-0559-0334-09, 09-0559-0334-11

Multi-Reagent Starter Kit

Create multifluidic circuits with up to 8 individual reagents and/or fluids, incorporating uProcess automated microfluidic valves.

Kit includes a AV801 (9-port, 8-position) valve and AV201 (3-port, 2-position) valve, as well as an SPS-01 automated syringe pump, uProcess software, fluid routing components and breadboard for easy construction.

The standard kit includes 5mL breadboard reservoirs. 1mL reservoirs (shown in image) can be substituted for additional cost (contact LabSmith for details).

5% off the cost of purchasing individual components.

Description Qty uProcess-C360-KIT
for 360µm Capillary
uProcess-T132-KIT
for 1/32" Tubing
uProcess-T116-KIT
for 1/16" Tubing
Electronic interface controller with uProcess software 1 EIB200 EIB200 EIB200
3-port, 2-position automated valve 1 AV201-C360 AV201-T132 AV201-T116
9-port, 8-position automated valve 1 AV801-C360 AV801-T132 AV801-T116
4-channel valve manifold 1 4VM02
Syringe pump with syringe glass and plunger set
1

SG-080-C360

SG-080-T132

SG-080-T116
Tool set for changing syringe glass/plunger 1 SPS-TOOLS
uProcess breadboard with 8 device connections 1 uPB-08
Mounting tools and hardware set for uPB-08 1 BB-TOOLS
One-Piece fitting 25 C360-100 T132-100 T116-100
One-piece plug 20 C360-101 C360-101 T116-101
5 mL breadboard reservoir  8 BBRES-C360-5ML BBRES-T132-5ML BBRES-T116-5ML
PEEK capillary or tubing (meters) 1m CAP360-150P TUBE132-010P TUBE116-030P

Typically ships within 1 week.

Microfluidic Kit - multi-reagent microfluidic kit, automated microfluidic valves, uProcess

Thermal Control Starter Kit

The Thermal Control Starter Kit lets you precisely heat and cool their micro-system using the uProcess software.  The uThermal products interface with the rest of the LabSmith uProcess™ product line, which includes syringe pumps, automated valves, pressure sensors and connectors for complete microfludic control. The kit includes a 5% discount off individual component prices.

The uProcess™ product line is a modular breadboard platform for researchers to create and control microfluidic circuits, prototypes and platforms. uProcess™ software lets you program sequences of syringe pump actuations.

Description Qty uThermal-PKG
uTE thermal electric Peltier module (select 2). Includes conductive tape. 2

uTE02-040808

uTE02-132020

uTS temperature sensor (select 2) 2 uTS01-STD-20

uTS01-STD-60

4 channel power manifold  1 4PM01
4 channel analog sensor manifold  1 4AM01
uProcess USB interface controller with software  1 EIB200
uProcess breadboard with 5 device connections 1 uPB-05
Peltier heat sink (select 2) 2

HS-0808

HS-2020

Mounting and installation accessories  1 ea.

uTE and uTS mounting screws, LS-TORX

Typically ships within 1 week.

microfluidics kit, microfluidic thermal control kit, ute-01 thermal control module, labsmith

Valve Starter Kit

The Valve Starter Kit includes everything you need to incorporate uProcess automated microfluidic valves into your microfluidic setup. The Valve Kit includes a 5% discount off individual component pricing.

The uProcess™ product line is a modular breadboard platform for researchers to create and control microfluidic circuits. uProcess™ software lets you program sequences of valve and syringe pump actuations. Products interface directly with LabSmith’s CapTite™ Microfluidic Products.

 Description

 Qty

 AV201-C360-PKG

for 360µm Capillary

 AV201-T132-PKG

for 1/32” Tubing

 AV201-T116-PKG

for 1/16” Tubing

Two-position Automated Valve 2 AV201-C360 AV201-T132 AV201-T116
4 Valve Manifold 1 4VM02 4VM02 4VM02
EIB200 (USB) uProcess Interface, includes uProcess software  1 EIB200 EIB200 EIB200
uProcess breadboard with 5 device connections 1 uPB-05 uPB-05 uPB-05
One-piece fitting, interfaces valve with capillary tubing 10 C360-100 T132-100 T116-100
Tools for component & breadboard installation 1 ea.

LS-HEX

LS-TORX

LS-Screws.25

LS-HEX

LS-TORX

LS-Screws.25

LS-HEX

LS-TORX

LS-Screws.25

Typically ships within 1 week

microfluidic kit, microfluidic pressure sensor kit, ups pressure sensor

Continuous Dispense Syringe Kit

The uProcess™ product line is a modular breadboard platform for researchers to create and control microfluidic circuits, prototypes and platforms. The uProcess™ software allows the user to program sequences of valve and syringe pump actuations. Products interface directly with LabSmith’s CapTite™ Microfluidic Products.




Example continuous dispense setup.

The CD-PKG package includes the components needed to maintain a continuous flow into a microfluidic system. Kit prices include a 5% discount off individual component pricing.

Description Qty uProcess-CD-C360-PKG

  for 360µm OD

uProcess-CD-T116-PKG

  for 1/16" OD

uProcess-CD-T132-PKG

  for 1/32" OD

Electronic interface controller with uProcess software 1 EIB200 EIB200  EIB200
Two-position 4-Port Automated Valve  1 AV202-C360 cAV202-T116  AV202-T132
Manifold for control of up to 4 automatic valves 1 4VM02 4VM02  4VM02
SPS01 syringe pump with syringe glass and plunger set  2

SPS01-004-C360

SPS01-020-C360

SPS01-080-C360



SPS01-020-T116

SPS01-080-T116

SPS01-020-T132

SPS01-080-T132

uProcess breadboard with 5 device connections  1 uPB-05  uPB-05   uPB-05
Breadboard reservoir 1 BBRES-5ML-C360 BBRES-5ML-T116  BBRES-5ML-T132
One-piece fitting for connecting capillary  10 C360-100 CT116-100  T132-100
One-piece plug   2 C360-101 T116-101  T132-101
Tubing/capillary 1 CAP30-150P TUBE116-030P TUBE132-010P
Component & breadboard installation tools   1 ea. SPS-TOOLS, LS-HEX, LS-TORX, LS-Screws.25 SPS-TOOLSLS-HEXLS-TORXLS-Screws.25  SPS-TOOLSLS-HEXLS-TORXLS-Screws.25

Typically ships within 1 week.

Microfluidics kit - Continuous Dispense Syringe Kit - uProcess Automation

Syringe Starter Kit

The Syringe Starter Kit includes everything you need to incorporate a uProcess programmable syringe pump into your microfluidic setups. The kit includes a 5% discount off individual component prices.

The uProcess™ product line is a modular breadboard platform for researchers to create and control microfluidic circuits. uProcess™ software lets you program sequences of valve and syringe pump actuations. Products interface directly with LabSmith’s CapTite™ Microfluidic Products.

Description  Qty

 SPS01-C360-PKG

for 360 µm Capillary

 SPS01-T116-PKG

for 1/16” Tubing

 SPS01-T132-PKG

for 1/32” Tubing

SPS01 syringe pump with 1 syringe glass and plunger set 1

SPS01-004-C360

SPS01-020-C360

SPS01-080-C360

SPS01-020-T116

SPS01-080-T116

 SPS01-020-T132

SPS01-080-T132

EIB200 (USB) uProcess interface, includes uProcess software 1 EIB200 EIB200  EIB200
uProcess breadboard with 5 device connections 1 uPB-05 uPB-05  uPB-05
Tool set for changing syringe glass/plunger 1 SPS-TOOLS SPS-TOOLS  SPS-TOOLS
One-piece fitting, interfaces syringe with capillary tubing 2 C360-100 T116-100  T132-100

Typically ships within 1 week.

microfluidic kit, microfluidic syringe starter kit

Pressure Sensor Starter Kit

The uProcess™ product line is a modular breadboard platform for researchers to create and control microfluidic circuits, prototypes and platforms. The uProcess™ software allows the user to program sequences of syringe pump actuations. Products interface directly with LabSmith’s CapTite™ Microfluidic Products.

The Pressure Sensor Starter Kit lets you measure and control pressure in your microfluidic system, circuit, prototype or platform. The kit offers a 5% discount off individual component prices.

Description Qty uPS-C360-PKG

for 360µm OD Capillary

uPS-T132-PKG

for 1/32” OD Tubing

uPS-T116-PKG

for 1/16” OD Tubing

uPS Pressure Sensor 2

uPS-0800-C360-10

uPS-0250-C360-10

uPS-0800-C360-10

uPS-0250-C360-10

uPS-0800-T116-10

uPS-0250-T116-10

4 Sensor Manifold 1 4AM01 4AM01 4AM01
EIB200 (USB) uProcess Interface, includes uProcess software 1 EIB200 EIB200 EIB200
uProcess breadboard with 5 device connections 1 uPB-05 uPB-05 uPB-05
Tee Interconnect 2 C360-203 T132-203 T116-203
One-piece fitting, interfaces sensor with capillary tubing 5 C360-100 T132-100 T116-100
Tools for component & breadboard installation 1 ea.

LS-HEX

LS-TORX

LS-Screws.50

LS-HEX

LS-TORX

LS-Screws.50

LS-HEX

LS-TORX

LS-Screws.50

Typically ships within 1 week.

microfluidic kit, microfluidic pressure sensor kit, ups pressure sensor

Weir-Filter Chip

Type: Weir Filter.

Design: Fluidic 1190.

Fluidic interface: Luer.

Material: Topas.

Description: Trapping chamber (barrier) chip, height: 500 µm, barriers: 40 µm on either side.

Lid thickness: 140 µm.

10001630, trapping chamber chip, fluidic 1190, luer, topas,microfluidic chipshop,labsmith

Weir-Filter Chip

Type: Weir-Filter.

Design: Fluidic 1329.

Fluidic interface: Mini Luer.

Material: Zeonor.

Barrier Chamber Chip.

Lid thickness: 188µm.

Barrier Chip 10001797,fluidic 1329, Zeonor,Microfluidic ChipShop, LabSmith

Weir-Filter Chip

Type: Weir Filter.

Design: Fluidic 220.

Fluidic interface: Mini Luer.

Material: Topas.

Channel dimension: 500 µm W x 500 µm D

Slit dimensions:

Structure 1: 7 mm W, 20 µm H
Structure 2: 7 mm W, 10 µm H
Structure 3: 7 mm W, 10 µm H
Structure 4: 7 mm W, 5 µm H.

Lid thickness: 140 µm.

Weir-Filter,  Barrier Chip 10000499, 14-1031-0220-02, Topas,Microfluidic ChipShop, LabSmith

Mini Luer Tube Tuck Connector

Type: Fluid Connector.

Design: Fluidic 997.

Chip interface: Mini Luer.

Fluidic interface: Tube Tuck.

Material: Green TPE.

Quantity per pack: 10.

male mini luer tube tuck connector, single,10001764, microfluidic chipshop,labsmith

Mini Luer Fluid Connector – Opaque

Type: Fluid Connector - Twin.

Design: Fluidic 332.

Fluidic interface: Mini Luer.

Material: Opaque PP.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Quantity per pack: 10.



male mini luer fluid connector, 10000425

Mini Luer Connector – Opaque

Type: Fluid Connector - row of four.

Design: Fluidic 333

Chip interface: Mini Luer.

Fluidic interface: Male.

Material: Opaque PP.

Quantity per pack: 10.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

male mini luer fluid connector, 10000321

Mini Luer Tube Tuck Connector

Type: Fluid Connector.

Design: Fluidic 997.

Chip interface: Mini Luer.

Fluidic Interface: Tube Tuck.

Material: Yellow TPE.

Quantity per pack: 10.



male mini luer tube tuck connector, single,10001765, microfluidic chipshop,labsmith

Field-Flow Fractionation Chip

Type: Field-Flow Fractionation.

Design: Fluidic 120.

Material: Zeonor.

Fluidic interface: Olive.

Lid thickness: 188 µm



field-flow fractional chip, zeonor, olives,10000334, 14-1021-0120-05, microfluidic chipshop, labsmith

Pillar Chip

Type: Pillar.

Design: Fluidic 261.

Fluidic interface: Mini Luer.

Material: Zeonor.

Pillar 1:

Diameter: 100µm
Distance: 350µm
Depth: 150µm.

Pillar 2:
Diameter: 150µm
Distance: 400µm
Depth: 150µm.

Pillar 3:
Diameter: 200µm
Distance: 500µm
Depth: 200µm.

Pillar 4:
Diameter: 250µm
Distance: 600µm
Depth: 200µm.

Pillar 5:
Diameter: 300µm
Distance: 700µm
Depth: 250µm.

Pillar 6:
Diameter: 350µm
Distance: 800µm
Depth: 250µm.

Pillar 7:
Diameter: 150µm
Distance: 500µm
Depth: 300µm.

Pillar 8:
Diameter: 150µm
Distance: 500-700µm
Depth: 300µm.

Lid Thickness: 188 mm.

microfluidic chip,pillar chip, Zeonor, Mini Luer, 10000099, 19-1801-0261-05, microfluidic chipshop, labsmith

Weir-Filter Chip

Type: Weir-Filter.

Design: Fluidic 220.

Fluidic interface: Mini Luer.

Material: Zeonor.

Channel dimension: 500µm W x 500µm D

Slit dimensions:

Structure 1: 7mm W, 20µm H
Structure 2: 7mm W, 10µm H
Structure 3: 7mm W, 10µm H
Structure 4: 7mm W, 5µm H.

Lid thickness: 183µm.

Weir-Filter,  Barrier Chip 10000093, 14-1031-0220-05, Microfluidic ChipShop, LabSmith

Education Kit

Teach Microfluidics with Easy-to-Use Components and Automation

LabSmith's microfluidics education kit helps students learn the fundamentals of constructing and automating microfluidic flows.


The kit is geared toward introductory college students and includes instruction for co-mixing experiment, patterned flow, and gradient flow, with endless variations as kit components are fully reusable.

1 to 4 students can participate with each kit. No previous microfluidics or programming experience is required. Step-by-step instruction and support videos help students accomplish fluid routing, automation and scripting tasks, to build a basic setup as well as more complex circuits.

Students will learn:

  • basic microfluidic systems and principles
  • assembly of leak-free microfluidic circuits
  • fluid routing, switching and mixing
  • microfluidic chip functions and connections
  • automation of pumps and valves
  • scripting to control flows
  • calculation of Reynolds number
  • cleaning and reuse of components.

Kit contents

Product Name Qty Product Number
Electronic interface controller with uProcess software 1 EIB200
4-channel valve manifold 1 4VM02
3-port, 2-position automated valve 2 AV201-T116
Automated syringe pumps with glass and plunger 2 SPS01-080-T116
Pearl chain microfluidic mixing chip 1 10001975
uProcess breadboard 1 uPB-05
1-mL breadboard reservoir 2 BBRES-T116-1ML
5-mL breadboard reservoir 1 BBRES-T116-5ML
One-piece fittings 16 T116-100
One-piece plugs 7 T116-101
Tubing, 1/16” outside diameter FEP tubing 1m TUBE-116-030F
Luer tip manual syringe 1 LS_SYRINGE_LT
Luer Lock manual syringe 1 LS_SYRINGE_LL
Luer Lock adapter 1 T116-300A
Also includes custom chip holder, chip connectors and plugs, liquid dispense bottles, waste cups, mounting screws, screwdriver, and hex wrench.
Detailed assembly instructions and support documentation

Typically ships within 1 week.

Microfluidics education kit from LabSmith - teach microfluidics, learn microfluidics

Pearl Chain Mixer Chip

Type: Micro Mixer.

Design: Fluidic 658.

Fluidic interface: Mini Luer.

Material: Topas.

Micro Mixer - pearl chain mixer.

Lid thickness: 125 µm.

Micro Mixer - Pearl Chain Mixer, fluidic 658,10000759, microfluidic ChipShop

Herringbone Mixer Chip

Type: Micro Mixer.

Design: Fluidic 187.

Fluidic interface: Luer.

Material: PC.

Herringbone Mixer Chip Design.

Channel depth: 100 µm.

Channel width inlet: 300 µm.

Channel width mixer: 600 µm.

Channel width outlet: 600 µm.

Lid thickness: 175 µm.





Micro Mixer - Herringbone Mixer, Luer,PC, 10000019,14-1037-0187-03

Herringbone Mixer Chip

Type: Micro Mixer.

Design: Fluidic 187.

Fluidic interface: Luer.

Material: Zeonor.

Description: Herringbone Mixer Chip.

Channel depth: 100 µm.

Channel width inlet: 300 µm.

Channel width mixer: 600 µm.

Channel width outlet: 600 µm.

Lid thickness: 188 µm.





Micro Mixer - Herringbone Mixer, P/N 10000076,14-1038-0187-05

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 189.

Fluidic interface: Luer.

Material: Topas.

Extended Length Cross channel chip with two perpendicular channels.

Channel dimensions: 50 µm wide x 50 µm deep x 127 mm long.

Lid Thickness: 140 µm.

Fluidic 189 - cross channel chip - 10000349 - microfluidic ChipShop

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 82.

Fluidic interface: Luer.

Material: Zeonor.

Cross channel chip with two perpendicular channels.

Channel dimensions: 50 µm wide x 50 µm deep x 87 mm long.

Lid Thickness: 100 µm.

Cross-channel Luer Chip,10000290

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 285.

Fluidic interface: Mini Luer.

Material: Topas.

Multi-channel design.

Lid thickness 140 µm.



Droplet Generator Chip, Multi Channel Design, P/N 10000175, 13-1006-0285-02

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 134.

Fluidic interface: Mini Luer.

Material: Zeonor.

Rhombic chamber chip eP2.

Chamber dimensions:

1: Volume: 60 µl, Depth: 540 µm

2: Volume: 40 µl, Depth: 540 µm

3: Volume: 20 µl, Depth: 400 µm

4: Volume: 20 µl, Depth: 400 µm

5: Volume: 10 µl, Depth: 200 µm

6: Volume: 10 µl, Depth: 200 µm

Lid thickness: 188 µm.

Rhombic chamber chip eP2, Microfluidic ChipShop, P/N 10000121,12-0941-0134-05

Mini Luer Plug – Opaque

Type: Plug.

Design: Fluidic 793.

Chip interface: Mini Luer.

Material: TPE.

Color: Opaque.

Description: Single, one-wing, low volume displacement.

Quantity: 10.

One-wing Mini Luer Male Plug Low Volume Displacement, 10001068, Microfluidic ChipShop

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 172.

Fluidic interface: Mini Luer.

Material: Zeonor.

Rhombic chamber chip eP1.

Chamber dimensions: 120 µL volume, 500 µm depth.

Lid thickness: 188 µm.

Microfluidic Chip - Rhombic Chamber Chip eP1,P/N 10000113,12-0904-0172-05,Microfluidic ChipShop

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 584.

Fluidic interface: Mini Luer.

Material: Zeonor.

Chamber dimensions: 20 µL volume, 500 µm deep.

Lid thickness: 188 µm.

Reaction chamber chip, 10000556, Microfluidic ChipShop, Mini-Luer, Zeonor,  Fluidic 584

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 584.

Fluidic interface: Mini Luer.

Material: PC.

Chamber dimensions: 20 µL volume, 500 µm deep.

Lid thickness: 175 µm.



Reaction chamber chip, 10000555, Microfluidic ChipShop, Mini-Luer, PC,  Fluidic 584

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 584.

Fluidic interface: Mini Luer.

Material: Topas.

Chamber dimensions: 20 µL volume, 500 µm deep.

Lid thickness: 140 µm.

Reaction chamber chip, 10001294, Microfluidic ChipShop, Mini Luer, Topas,  Fluidic 584

Membrane Chip

Type: Membrane.

Design: Fluidic 747

Interface: Mini Luer.

Material: PS.

Cross flow membrane chip.

Pore size: 8 mm.

Lid thickness: 125 mm.



Cross-flow Membrane Chip 10001019, formerly 15-1555-0747-07, fluidic 747.

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 947.

Fluidic interface: Mini Luer.

Material: Topas.

Multi-channel design.

Lid thickness: 100 µm.

Microfluidic Chip - Droplet Generator- Multichannel Design (P/N 10001336)

Oil for Droplet Generation

Type: Droplet Oil.

Description: MCS-OIL-10 oil for droplet generation. Compatible with PC, PMMA, COC (Topas), COP (Zeonor).

Quantity: 10 ml.

Oil for droplet generation. P/N 10000677, MCS-OIL-10, Compatible with PC, PMMA, COC (Topas), COP (Zeonor).

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 912.

Fluidic interface: Mini Luer.

Material: Topas.

Description: Multi-channel design, single cross geometry.

Lid thickness 140 µm.



Microfluidic ChipShop Droplet Generator chip, multi-channel design, single cross geometry (P/N 10001332)

Titer Plate Chip

Type: Titer Plate.

Design: Fluidic 18.

Fluidic Interface: Through Hole.

Material: PC.

Titer Plate- microscopy slide format.

Well depth: 20 µm.

Well size; Structure 1: Top 124 µm, Bottom 96 µm; Structure 2: Top 224 µm, Bottom 196 µm; Structure 3: Top 424 µm, Bottom 396 µm

Well spacing: Structure 1: 281.25 µm; Structure 2: 562.5 µm; Structure 3: 1125 µm

Microfluidic  ChipShop Titer Plate - Microscopy Slide Format, 10000201, Fluidic 18

Titer Plate Chip

Type: Titer Plate.

Design: Fluidic 18.

Fluidic Interface: Through Hole.

Material: PMMA.

Titer plate- microscopy slide format (chips are labeled Nanotiter plate)

Well depth: 20µm.

Well size: Structure 1: Top 124 µm, Bottom 96 µm; Structure 2: Top 224 µm, Bottom 196 µm; Structure 3: Top 424 µm, Bottom 396 µm

Well spacing: Structure 1: 281.25 µm; Structure 2: 562.5 µm; Structure 3: 1125 µm

Microfluidic  ChipShop Titer Plate - Microscopy Slide Format, 10000199, Fluidic 18

Mini Luer Interface Kit

The Mini Luer Interface Kit includes fittings and disposable syringes for manual dispensing of microfluidic volumes.



Description Qty Part Number
Mini Luer fluid connector 3 N/A*
Luer-tip Disposable Syringes 3 LS-SYRINGE_LT
Syringe Adapters 3 10000614
Silicone Tubing 1m 10000033

* Adapters are available through LabSmith in packs of 10, P/N 10000094.

Microfluidics Mini-Luer Interface Kit with disposable syringes, fittings and capillary

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 1003.

Fluidic interface: Mini Luer.

Material: Zeonor.

Chamber dimensions: 27 mL volume, 350 mm deep.

Lid thickness: 188 mm.

Reaction chamber chip, Microfluidic ChipShop, Mini Luer, Zeonor,  Fluidic 1003

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 1003.

Fluidic interface: Mini Luer.

Material: Topas.

Chamber dimensions: 27 µL volume, 350 µm deep

Lid thickness: 140 µm

Reaction chamber chip, Microfluidic ChipShop, Mini Luer, Topas,  Fluidic 1003

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 132.

Fluidic interface: Mini Luer.

Material: Topas.

Description: Rhombic chamber chip eP2.

Chamber dimensions: 6 mL volume, 200 mm deep.

Lid thickness: 140 mm.

Rhombic chamber chip eP2, Microfluidic ChipShop, P/N 10000034,12-0922-0132-02

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 180.

Fluidic interface: Olive.

Material: Topas.

Description: Straight-channel chip with 4 parallel channels; channel dimensions: 800 µm wide x 20 µm deep x 58.5 mm long.

Lid thickness: 140 µm.

Straight 4-channel Chip, Topas, Olive, 10000216, 01-0206-0180-02, Microfluidic ChipShop

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 440.

Fluidic interface: Mini Luer.

Material: PC.

Multi-channel design.

Lid thickness 175 µm.

Droplet Generator Chip Mini-Luer 10000174 13-1008-0440-03 Microfluidic ChipShop

Droplet Generation Chip

Type: Droplet Generator.

Design: Fluidic 719.

Fluidic interface: Mini Luer.

Material: Topas.

Description: Droplet generation and storage chip.

Lid thickness 140 µm.

Droplet Generation and Storage Chip Mini-Luer 10000751- Microfluidic ChipShop

PCR Chip

Type: PCR.

Design: Fluidic 243.

Fluidic interface: Olive.

Material: Zeonor.

Chip with meandering channels for continuous flow PCR.

Channel dimensions: 600 mm wide x 300 mm deep x 1637 mm length.

Notes: 40 cycles (1 inlet, 1 outlet).

Lid thickness: 188 mm.

Microfluidic Chip - Meander and Continuous Flow PCR Chip, Olive, Zeonor, 10000011, Microfluidic ChipShop

PCR Chip

Type: PCR

Design: Fluidic 47.

Material: PC.

Interface: Olive.

PCR chip with meandering channels for continuous flow.

Channel dimensions: 500 mm wide x 100 mm deep x 810 mm length.

Notes: 15 cycles (1 inlet, 1 outlet)

Lid thickness: 175 mm.

Microfluidic Chip - Meander Continuous Flow, PCR Chip, Olive, PC,10000008 08-0470-0047-03-Microfluidic ChipShop

Syringe Adapter, Single

Type: Syringe Adapter.

Material: PP.

Description: OD: 1.7 mm; ID: 0.5 mm; length: 55 mm.

Quantity: 1

Former Part Number: 11-0805-0000-00.

Syringe Adapter Single 10000614 11-0805-0000-00 Microfluidic ChipShop

Waste Chamber Chip

Type: Waste Chamber.

Design: Fluidic 95.

Fluidic interface: Luer.

Material: PMMA.

Straight-channel chip with waste chamber.

Channel dimensions: 3000 µm wide x 200 µm deep x 36 mm long.

Chamber volume: 75 µL.

Lid thickness: 175 µm.

Straight Channel Luer Chip with Waste Chamber - 10000429 - Microfluidic ChipShop

Straight Channel Chip – Open Platform

Type: Straight Channel.

Design: Fluidic 268.

Fluidic interface: Luer.

Material: PMMA.

Straight-channel chip with 1 channel.  Open platform chip for self-assembly

Channel dimensions: 2500 µm wide x 150 um deep x 58.5 mm long.

Lid thickness: 175 µm.

Straight Channel Luer Chip 10000376 - Microfluidic ChipShop

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 163.

Material: Topas.

Fluidic interface: Mini Luer.

Description: One channel design; input channel width: 140 µm; collection channel width: 420 µm; channel depth: 140 µm.

Lid thickness: 140 µm.

fluidic 163, Droplet Generator Chip 10000006 , Mini-Luer, Topas, 13-1003-0163-02 Microfluidic ChipShop

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 162.

Fluidic interface: Mini Luer.

Material: Topas.

Description: One channel design, input channel width: 70 µm, collection channel width: 210 µm, channel depth: 70 µm, lid thickness: 140 µm.

Droplet Generator Chip, Mini-Luer, Topas, 10000005 - Microfluidic ChipShop

Droplet Generator Chip

Type: Droplet Generator.

Design. Fluidic 536.

Fluidic interface: Luer.

Material: PC.

Droplet generator chip with three elements on one chip.

Lid thickness 175 µm.

Droplet Generator Chip Luer 10000509 - Microfluidic ChipShop

Spiral Sorting Chip

Type: Sorting.

Design: Fluidic 382.

Fluidic Interface: Mini Luer.

Material: PMMA.

Description: Particle and cell sorting chip - spiral sorter chip contains 4 sorting structures.

Structure dimensions:

Structure 1 Structure 2 Structure 3 Structure 4
No. of turns 4 8 9 12
No. of outlets 8 8 6 6
Channel width 500 µm 300 µm 150 µm 80 µm
Channel depth 120 µm 80 µm 70 µm 50 µm









Lid thickness: 175 µm.

Spiral Sorter Chip 10000159 - Microfluidic ChipShop

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 180.

Fluidic interface: Mini Luer.

Material: PMMA.

Straight-channel chip with 4 parallel channels.

Channel dimensions: 800 µm wide x 20 µm deep x 58.5 mm long.

Lid thickness: 175 µm.

Straight 4-channel Mini-Luer Chip 10000108 - Microfluidic ChipShop

Mini Luer to Pipette Adapter – Yellow

Type: Fluid Connector.

Design: Fluidic 0391.

Chip interface: Mini Luer.

Fluidic interface: Pipette.

Material: Yellow PP.

Quantity per pack: 10.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Mini Luer to pipette adapter, Microfluidic ChipShop, 10000057, 09-0565-0391-09

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 143.

Fluidic interface: Mini Luer.

Material: PMMA.

Straight channel chip with 4 parallel channels.

Channel dimensions: 20 µm wide x 20 µm deep x 58.5 mm long.

Lid thickness: 175 µm.

Microfluidic Chip - Straight Channel Chip (P/N 10000038)

Mini Luer to Luer Adapter

Type: Fluid Connector.

Design: Fluidic 390.

Chip Interface: Mini Luer

Fluid Interface: Luer

Material: Opaque PP.

Description: Single, Mini Luer to Luer adapter.

Quantity per pack: 10

mini luer to luer adapter, 10000063

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 145.

Fluidic interface: Mini Luer.

Material: PMMA.

Straight-Channel Chip with 4 Parallel Channels

Channel dimensions: 50 µm wide x 50 µm deep x 58.5 mm long.

Lid thickness: 175 µm.

Microfluidics chip - Straight 4-channel Chip Mini-Luer Chip (P/N 10000086)

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 440.

Fluidic interface: Mini Luer.

Material: Topas.

Description: Multi-channel design.

Lid thickness: 140 µm.

Microfluidic Chip -  Droplet Generator- Multi Design (P/N 10000040)

Diffusion Mixer Chip

Type: Micro Mixer.

Design: Fluidic 186.

Fluidic interface: Luer.

Material: Zeonor.

Diffusion Mixer Chip

Channel depth: 100 µm.

Channel width inlets: 100/200 µm.

Channel width mixer: 200 µm.

Channel width outlet: 200 µm.

Lid thickness: 188 µm.

fluidic 186, micro mixer, microfluidic chipshop

Electrophoresis Starter Kit

The Electrophoresis Starter Kit includes everything you need to incorporate uEP01 Electrophoresis Power Modules into your electrophoresis or dielectrophoresis setup, to control voltage using uProcess software. Kit includes two sets of cables.

The Electrophoresis Starter Kit include a 5% discount off individual component prices.

NOTE: Accompanying image shows setup with Electrophoresis Starter Kit. Microfluidic chip is not included.

Description Qty Electrophoresis-PKG
300 V Electrophoresis Power Supplies, includes cables 2 uEP01-300
uProcess USB interface controller with software 1 EIB200
uProcess breadboard with 5 device connections 1 uPB-05
Set of two microclips (one each red and black) 2 A-MC2-01
Platinum electrode wire, 0.584 mm dia (23 gauge); 10 cm length 1 A-PT-ELECTRODE

Typically ships within 1 week.

LabSmith Electrophoresis Starter Kit, microfluidic kit, uEP300 Electrophoresis Power Module

Through Hole Fluid Connector

Type: Fluid Connector - Single.

Design: Fluidic 631.

Chip interface: Through Hole.

Fluid interface: Mini Luer.

Material: Opaque PP.

Quantity per pack: 10.

female luer connector, 100000701

Tank with Luer Interface

Type: Tank.

Design: Fluidic 639.

Chip Interface: Luer.

Material: PP.

Description: Single, 500 µl volume, cap with Mini Luer interface (without venting membrane in cap).

Quantity: 10 single tanks.

Microfluidic Tanks 500 ul Luer Interface with Cap Mini Luer Interface 10000761  16-0618-0639-09 Microfluidic ChipShop

Waste Chamber Chip

Type: Waste Chamber.

Design: Fluidic 272.

Fluidic interface: Mini Luer.

Material: PMMA.

Straight Channel Chip with Waste Chamber.

Channel dimensions: 2500 µm wide x 200 µm deep x 26 mm long.

Lid thickness: 175 µm.

Tank with Luer Interface

Type: Tank.

Design: Fluidic 833.

Chip Interface: Luer.

Material: PP.

Description: Single, 200 ml volume, includes venting cap without venting membrane.

Quantity: 10 single tanks.

Microfluidic Tanks 200 ul Luer Interface Venting Cap 10000991, Microfluidic ChipShop

Heat Sink

Black anodized aluminum heat sink for use with uTE Thermal Electric Modules. Choose from two sizes. Adhesive backing.



Part Number Size (mm)
HS-0808 8.9 x 8.9 x 5
HS-2020 20 x 20 x 5



uTS temperature sensor is recommended for monitoring and control of the uTE module.

Typically ships within 2-3 days.

microfluidic thermal control, heat sink for peltier

Micro Clip Set A-MC2-01

Micro-clip set for use with uEP01 cables and with A-EHVC12 cable set for the uEP300-12 high-voltage power supply. Includes one red and one black clip.

high voltage cable, microclips, micro-clips, micro clips

A-EHVC12 Cable Set for uEP300-12 Power Supply

The A-EHVC12 kit includes 24 high-voltage cables for use with the uEP300-12 electrophoresis power supply.

The kit includes 12 black and 12 red cables with friction fit terminals. All cables are 60" (150 cm) long.

A-EHVC12 Cable Set for uEP300-12 Power Supply

uEP300-12 Power Supply for Electrophoresis and Gel Electrophoresis

12-channel Precision High-Voltage Supply for Electrophoresis and Gel Electrophoresis

The uEP300-12 is a twelve-channel, fully programmable power supply for control of electrophoresis and gel electrophoresis setups. Each channel can provide constant voltage to 300 V, constant current to 0.25 A, or constant power to 15 W (max 180 W all channels).

The uEP300-12 is part of LabSmith’s uProcess™ automation platform, which includes hardware devices and uProcess software for constructing, coordinating and automating microfluidic systems. The uProcess software (included with the uEP300-12) lets you control and integrate the instrument into complete systems. You can also use the uEP300-12 in conjunction with uProcess pressure sensors and temperature sensors for constant pressure or temperature modes.

The uEP300-12 is also available uncased for OEM applications. Contact LabSmith for more details.

Specifications Maximum Minimum Step Size
Channels 12 individually controllable channels
Output Voltage 300 V/channel 10 mV
Output Current 0.25 A/channel 10 uA
Output Power 15 W/channel (180 W max all channels)
Dimensions 35.6 cm x 10.2 cm x 9 cm (14” x 4.0” x 3.5”);  2.3 kg (5 lb)
Optional Cables and Clips
The A-EHVC12 high-voltage interface cable set (sold separately) includes 12 black and 12 red cables, all 60" (150 cm) long, with friction fit terminals. The A-MC2-01 micro clips can be used with the A-EHVC12 cables. Electrodes are sold separately.



Need just one or two channels? The uEP01-300 is a modular version of the uEP300-12 channel. The uEP01 is available as part of LabSmith’s uProcess product line and is also available in OEM configurations.
LabSmith uEP300-12 12-channel high voltage power supply for electrophoresis and gel electrophoresis

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 537.

Fluidic interface: Luer.

Material: PC.

Four elements on one chip design.

Lid thickness 175 µm.



Spiral Sorting Chip

Type: Sorting.

Design: Fluidic 382.

Fluidic Interface: Mini Luer.

Material: Zeonor.

Particle and cell sorting chip - spiral sorter. Chip contains 4 sorting structures.

Structure dimensions:

structure 1 structure 2 structure 3 structure 4
No. of turns 4 8 9 12
No. of outlets 8 8 6 6
Channel width 500 mm 300 mm 150 mm 80 mm
Channel depth 120 mm 80 mm 70 mm 50 mm









Lid thickness: 188 mm.

uProcess Electrophoresis Power Module uEP01-300

The uEP01-300 is an extremely compact, fully programmable high-voltage supply for controlling electrophoresis and gel electrophoresis setups. Measuring just 7.7 cm (3.0 in.) long, the uEP01 provides constant voltage to 300V, or current or power. Multiple modules can be controlled together for fully independent, multi-channel control.

The uEP01 is part of LabSmith’s uProcess™ automation platform, which includes hardware devices and uProcess software, for constructing and automating microfluidic systems. uProcess software lets you control one or more uEP01 modules and integrate them into complete systems. You can also use the uEP01 in conjunction with uProcess pressure sensors and temperature sensors for constant pressure or temperature modes.

Max voltage: 300 V

Max current: 0.25 A

Max power: 15 W

An EIB200 automation interface is required to control and monitor using the uEP300 using LabSmith's uProcess software.  An optional uProcess breadboard can be used to mount the EIB200, multiple uEP01 modules, and other uProcess devices and components.

Cables and Clips
Each uEP01 module includes 2 cables (one red and one black) with friction fit terminations for connection to electrodes or microclips. Optional A-MC2-01 micro-clips can be used with the cables to grab electrodes.



Need even more power? LabSmith’s new 12-channel uEP300-12 instrument combines twelve uEP01-300 modules, plus an automation interface and 180W power supply, all in a single unit.
Electrophoresis Power Supply - LabSmith uEP01-300

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 537.

Fluidic interface: Luer.

Material: Topas.

Four elements on 1 chip design.

Lid thickness: 140 µm.



Microfluidic Chip - Droplet Generator Chip (P/N 10000466)

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 536.

Fluidic interface: Luer.

Material Topas.

Double emulsion generator chip (droplet in droplet). 3 elements on 1 chip design.

Lid thickness 140 µm.



Silicone Tubing 0.76 mm ID

Type: Tubing.

Material: Silicone.

ID: 0.76 mm.

OD: 1.65 mm.

Qty 1 m.

See Tubing and Capillary for more options.

Microfluidic Silicone Tubing

Microtubes

Type: Tubing.

Material: PTFE.

ID: 0.5 mm.

OD: 1.0 mm.

Qty 1 m.

See Tubing and Capillary for more options.

Microfluidic microtubes (microtubing)

Optics Module with 5 MP B&W Camera

Optics module for the SVM340 Microscope with 5 MP black & white CMOS camera.  The module includes a mount for a fluorescence filter (not included) and threading for a standard DIN objective (not included).

Specifications:
Resolution: 2448 x 2048 pixel
Frame Rate: 38 fps at full resolution (up to 200 fps at reduced resolution)
Interface: USB3.0
Gain Control: auto or manual
Scan: progressive
Sensor: Sony IMX264LQ Pregius CMOS

Optics Module for SVM340 microscopes - with 5 MP B&W Camera (A-DP5-BW)

Optics Module with 5 MP Color Camera

Optics module with 5 MP color CMOS camera for the SVM340 Microscope.  The module includes a mount for a fluorescence filter (not included) and threading for a standard DIN objective (not included).

Specifications:
Resolution: 2448 x 2048
Frame Rate: 38 fps at full resolution (up to 200 fps at reduced resolution)
Interface: USB 3.0
Gain Control: auto or manual
Scan: progressive
Sensor: Sony IMX264LQ Pregius CMOS

Optics module with 5MP Black and white camera for LabSmith SVM inverted fluorescence microscopes

uProcess Automated 8-Position Selector Valve AV801

The LabSmith AV801 selector valve provides automated routing of microfluidic volumes. At 6.6 cm (2.6 in) high, the AV801 is a fraction of the size of other valves, making it ideal for microfluidics research and OEM applications.

The compact AV801 has 8 selector ports and one common port. The extremely small swept volume minimizes waste and enable high throughput. Fast, reliable geared switching ensures long life.


Sample microfluidic circuit using the AV801 and AV201 automated valves, and other uProcess automated components.

LabSmith’s AV801 valves are constructed with Vespel® as the wetted material*, for use with a wide variety of chemicals.

CapTite™ one-piece fittings provide leak-free connections to 1/32” OD, 1/16" OD or 360 micron OD capillary.

LabSmith’s miniaturized 4VM02 valve manifold provides control for up to four selector valves, with single-cable connections. The breadboard-mounted 4VM02 is far smaller than other valve controllers, offers additional savings in cost and size for OEM applications.

The AV801 selector valve is the newest component of LabSmith’s uProcess platform, which simplifies construction and control of microfluidic systems. Automated uProcess components include syringe pumps, temperature and pressure sensors, selector valves, temperature controllers and more. Microsoft Windows®-based uProcess software provides straightforward control of all devices. With uProcess users can generate automated scripts to control both simple setups or complex lab automation.

Requires a 4VM02 valve manifold and EIB200 interface controller for communicating with PC.  Connects to capillary via CapTite one-piece fittings (not included).



AV801-T116V:  Compatible with 1/16" OD capillary. Nine (9) T116-100 fittings required for interface to capillary (not included). Wetted material: Vespel.*

AV801-T132V:  Compatible with 1/32" OD capillary. Nine (9) T132-100 fittings required for interface to capillary (not included). Wetted material: Vespel.*

AV801-C360V:  Compatible with 360 um OD capillary. Nine (9) C360-100 fittings required for interface to capillary (not included). Wetted material: Vespel.*

* Selected valves are available with PCTFE Kel-F® as the wetted material. Contact LabSmith for pricing and availability.

microfluidics valve - uProcess automated microfluidic 9-port 8-position valve AV801

uProcess Manifold for Valve Control 4VM02

Manifold connects and controls up to four uProcess automatic valves. Can be mounted to uProcess Breadboard (uPB-5, uPB-8, uPB-12, or iBB).

Includes 4 flat flex ribbon cables (1 x 8", 2 x 10", 1 x 12").

uProcess microfluidic automation valve manifold 4VM02

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 161.

Fluidic interface: Mini Luer.

Material: PMMA.

Cross-channel chip. Microscopy slide format. Chip has two separate channel structures with crossing channels on each chip. One structure has an offset, the other is without an offset.

Channel dimensions: 80 mm wide x 80 mm deep x 53.3 mm long.

Lid thickness: 175 mm.

Microfluidics chip - Cross Shaped Channel Chip (P/N 10000303)

Silicone tubing 0.5mm ID

Type: Tubing.

Material: Silicone.

ID: 0.5 mm.

OD: 2.5 mm.

Qty 1 m.

See Tubing and Capillary for more options.

Microfluidic silicone tubing

Membrane Chip

Type: Membrane.

Design: Fluidic 480.

Fluidic interface: Mini luer.

Material: Topas.

Cross flow membrane chip.

Pore size: .2 mm.

Lid thickness: 140 mm.

Tank with Luer Interface

Type: Tank.

Design: Fluidic 387.

Chip interface: Luer.

Material: PP.

Description: Single, 500 ml volume.

Quantity: 10 single tanks.

Tank, Single with Luer Interface, 10000281, Microfluidic ChipShop

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 285.

Fluidic interface: Mini Luer.

Material: PC.

Multi-channel design.

Lid thickness 175 µm.

Droplet Generator Chip, Multi Channel Design, P/N 10000176, 13-1006-0285-03

Microfluidic Support Kit 1

The microfluidic support kit comprises components necessary for running microfluidic systems.

Microfluidic Support Kit

Includes:

microfluidic chip support kit - microfluidic chipshop accessories

Tank with Luer Interface

Type: Tank.

Design: Fluidic 233.

Chip interface: Luer.

Material: PP.

Description: Row of 4 tanks, 4.5 ml volume (each).

Quantity: 10 rows of 4 tanks.

Microfluidic tanks,  row of 4 with Luer Interface, 10000079, 16-0613-0233-09, Microfluidic ChipShop

Tank with Piercing Interface

Type: Tank.

Design: Fluidic 231.

Chip interface: Piercing.

Material: PP.

Description: Triple, 500 ml volume (each).

Quantity: 10 triple tanks.

Tanks - Triple with Piercing Interface 10000104 16-0603-0231-09 Microfluidic ChipShop

Tank with Piercing Interface

Type: Tank.

Design: Fluidic 230.

Chip Interface: Piercing.

Material: PP.

Description: Double, 500 ml volume (each).

Quantity: 10 double tanks.

Tanks - Double with Piercing Interface 10000103 16-0602-0230-09 Microfluidic ChipShop

Tank with Piercing Interface

Type: Tank.

Design: Fluidic 229.

Chip interface: Piercing.

Material: PP.

Description: Single tank; 500 ml volume.

Quantity: 10 single tanks.

single tank piercing 10000102

Membrane Chip

Type: Membrane.

Design: Fluidic 168.

Fluidic interface: Luer and Mini Luer.

Material: Topas.

Chip with 4 plasma generation membranes.

Membrane diameter: 10 mm.



fluiidic 158, membrane chip, plasma generation chip, 10000242, microfluidic chipshop

Meander Chip

Type: Meander.

Design: Fluidic 442.

Fluidic interface: Through Hole.

Material: Glass.

Chip with meandering channels, serving as reaction units as well as mixing devices.

Through hole diameter is 96 µm, with a spacing of 4.5 mm

Channel depth: 20 mm.

Former P/N: 14-1301-0442-20.





Microfluidic Chip - Glass Meander Chip, 10000295

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 440.

Fluidic interface: Through Hole.

Material: Topas.

This droplet generator chip is identical to microfluidic ChipShop catalog chip #10000040, except it has a through-hole interface instead of the mini-luer interface.

The design combines size variations of one main design for the evaluation of generated droplet size under the desired conditions. There are eight droplet generators on each chip with channel dimensions at the droplet formation region of 80 µm, 70 µm, 60 µm and 50 µm channel width and height. Each size version comes with two different outlet channel width.



Bonded port connectors can be used to interface the microfluidic chip to capillary tubing.

Droplet Generator Chip

Type: Droplet Generator.

Design: Fluidic 162.

Fluidic interface: Mini Luer.

Material: PC.

Channel dimensions: input channel width: 70 µm; collection channel width: 210 µm; channel depth: 70 µm.

fluidic 162, droplet generator chip, microfluidic chip, microfluidic chipshop

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 132.

Fluidic interface: Mini Luer.

Material: PMMA.

eP2 Rhombic chamber chip. Note: PMMA is not suitable for PCR applications.

Chamber dimensions: 6 mL volume, 200 mm depth.

Lid thickness: 175 mm.



Microfluidic Chip - Rhombic Chamber Chip (P/N 10000114)

Reaction Chamber Chip

Type: Reaction Chamber.

Design: Fluidic 172.

Fluidic interface: Mini Luer.

Material: PMMA.

Rhombic chamber chip eP1.

Chamber dimensions: 120 ml volume, 500 mm depth.

Lid depth:500 mm.

Microfluidic Chip - Rhombic Chamber Chip eP1 (P/N 10000110)

Mini Luer Fluid Connector – Row of 4

Type: Fluid Connector - row of 4.

Design: Fluidic 333.

Fluidic interface: Mini Luer.

Material: Opaque TPE.

Quantity per pack: 10.

Note: PP is a harder material that is easy to use for interfacing with tubing. TPE is softer, for easy closing of fluidic interfaces with minimal force.

Mini-Luer Male Fluid Connector, Row of 4, 10000118, Microfluidic ChipShop

Mini Luer Plug

Type: Plug.

Design: Fluidic 336.

Chip interface: Mini Luer.

Material: TPE.

Color: Opaque.

Description: Row of 4.

Quantity: pack of 10.

male mini_luer plug, row of 4,10000056

Mini Luer Plug – Opaque

Type: Plug.

Design: Fluidic 336.

Fluidic interface: Mini Luer.

Material: PP.

Color: Opaque.

Description: Row of 4.

Quantity: 10.

Mini Luer Plug, Row of 4, 10000345

Mini Luer Plug

Type: Plug.

Design: Fluidic 335.

Chip interface: Mini Luer.

Material: PP.

Color: Opaque.

Description: Row of 2.

Quantity: 10.

Mini-Luer Male Twin Plug, 10000179, Microfluidic ChipShop

Through Hole Connector

Type: Fluid Connector.

Design: Fluidic 302.

Chip interface: Through Hole.

Fluid interface: Luer Lock.

Material: Opaque PMMA.

Quantity per pack: 10.

Notes: 1.3 mm diameter through hole size.

Female Luer Lock Compatible Connector 10000227, Microfluidic ChipShop

PCR Chip

Type: PCR.

Design: Fluidic 65.

Fluidic interface: Olive.

Material: PC.

PCR chip with long, meandering channels. 36 cycles, 2 inlets & 3 outlets.

Channel dimensions: 200 um wide x 100 um deep x 1257 mm long.

Lid thickness: 175 um.

Microfluidic Chip -  PCR Chip (P/N 10000007)

H-shaped Channel Chip

Type: H-shaped Channel.

Design: Fluidic 164.

Fluidic interface: Mini Luer.

Material: Topas.

Chip with 4 sets of H-shaped channels.

Channel dimensions:

Channel I Channel II Channel III Channel IV
Inlet & outlet width 75 µm 75 µm 150 µm 150 µm
Middle width 75 µm 150 µm 150 µm 300 µm



Microfluidic Chip - H-shaped Channel Mini-Luer Chip, 10000265

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 106.

Fluidic interface: Luer.

Material: Zeonor.

Cross channel chip with two perpendicular channels.

Channel dimensions: 75 mm wide x 75 mm deep x 87 mm long.

Lid Thickness: 100 mm.

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 166.

Fluidic interface: Luer.

Material: Topas.

Cross channel chip with two perpendicular channels.

Channel dimensions: 100 mm wide x 100 mm deep x 87 mm long.

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 106.

Fluidic interface: Luer.

Material: Topas.

Cross channel chip with two perpendicular channels.

Channel dimensions: 75 mm wide x 75 mm deep x 87 mm long.

Lid Thickness: 140 mm.

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 106.

Fluidic interface: Luer.

Material: PMMA.

Cross channel chip with two perpendicular channels.

Channel dimensions: 75 mm wide x 75 mm deep x 87 mm long.

Lid Thickness: 175 mm.

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 82.

Fluidic interface: Luer.

Material: Topas.

Cross channel chip with two perpendicular channels.

Channel dimensions: 50 wide mm x 50 deep mm x 87 mm long.

Lid Thickness: 140 mm.



Straight Channel Microtiter Plate

Type: Straight Channel.

Design: Fluidic 102.

Fluidic interface: Through Hole

Material: Zeonor.

Microtiter plate with 64 microchannels.

Channel dimensions: 2 mm wide x 0.15 mm deep x 18 mm long.

Surface treatment: hydrophilized.

Straight Channel Microtiter Plate

Type: Straight Channel.

Design: Fluidic 102.

Fluidic interface: Through Hole.

Material: Zeonor.

Straight channel microtiter plate with 64 microchannels.

Channel dimensions: 2 mm wide x 0.15 mm deep x 18 mm long.

Lid thickness: 188 um.

Microfluidics chip -Straight 64-channel Microtiter Plate (P/N 10000320)

Waste Chamber Chip

Type: Waste Chamber.

Design: Fluidic 95.

Fluidic interface: Luer.

Material: Topas.

Description: Straight channel chip with waste chamber; channel dimensions: 3000 µm wide x 200 µm deep x 36 mm long, chamber volume: 75 µL.

Lid thickness: 140 µm.

Waste Chamber Chip

Type: Waste Chamber.

Design: Fluidic 95.

Fluidic interface: Luer.

Material: PMMA.

Straight-channel chip with waste chamber.

Channel dimensions: 3000 µm wide x 200 µm deep x 36 mm long.

Chamber volume: 75 µL.

Lid thickness: 175 µm.



Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 152.

Fluidic interface: Olive.

Material: Topas.

Straight channel chip with 16 parallel channels.

Channel dimensions: 1000 mm wide x 200 mm deep x 18.0 mm long.

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 142.

Fluidic interface: Olive.

Material: Topas.

Straight-channel chip with 16 channels.

Channel dimensions: 200 µm wide x 100 µm deep x 18 mm long.

Lid thickness: 140 µm.

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 166.

Fluidic interface: Through Hole.

Material: PMMA.

Cross channel chip with two perpendicular channels.

Through hole diameter: 1 mm.

Channel dimensions: 100 µm wide x 100 µm deep x 87 mm long.

Lid Thickness: 175 µm.



Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 82.

Fluidic interface: Through Hole.

Material: PMMA.

Cross channel chip with two perpendicular channels. Note: 0.5 mm through hole size.

Channel dimensions: 50 mm wide x 50 mm deep x 87 mm long.

Lid Thickness: 175 mm.

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 82.

Fluidic interface: Through Hole.

Material: Topas.

Description: Cross channel chip with two perpendicular channels; 0.5 mm through hole size; channel dimensions: 50 mm wide x 50 mm deep x 87 mm long.

Lid Thickness: 140 mm.

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 144.

Fluidic interface: Mini Luer.

Material: TOPAS.

Straight-channel chip with 4 parallel channels.

Channel dimensions: 100 µm wide x 100 µm deep x 58.5 mm long.

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 156.

Fluidic interface: Mini Luer.

Material: PMMA.

Straight-Channel Chip with 4 Parallel Channels.

Channel dimensions: 200 µm wide x 200 µm deep x 58.5 mm long.

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 157.

Fluidic interface: Luer.

Material: Topas.

Description: Straight channel chip with 8-parallel channels, channel dimensions: 100 µm wide x 100 µm deep x 18 mm long.

Power Manifold

Power manifold for automatable and closed-loop control of up to 4 uTE thermal-electric modules or other loads using the LabSmith uProcess microfluidic control software. Includes 4 flat flex ribbon cables (1 x 8", 2 x 10", 1 x 12").

Voltage range: –5 to 5 V
Current range: -4 to 4 A
Maximum Power: 15 W
Dimensions: 2.1" x 1.0" x 0.5" (54 mm x 26 mm x 13 mm)

Typically ships within 2-3 days.

uProcess microfluidic automation power manifold 4PM01

Thermal-Electric Module

LabSmith uTE-series thermal-electric module. The uTE module is used for heating or cooling your microfluidic application. The module can be coupled with a uTS temperature sensor for precision thermal monitoring and control using LabSmith's uProcess software. Other uProcess devices include the SPS01 syringe pumps, AV-series automated valves, and uPS pressure sensors.

Maximum temperature: 130° C

Part Number Size (mm) Qmax (W) Vmax (V) Imax (A)
uTE02-040808 8.3 x 8.3 x 2.3 4.3 3.9 2
uTE02-132020 20 x 20 x 4.0 13 3.7 6
uTE02-151530 15 x 30 x 3.7 15 4.2 6

The uTE-series thermal-electric modules require a 4PM01 Power Manifold and EIB200 uprocess interface. A uTS temperature sensor is recommended for monitoring and control of the uTE module.

Typically ships within 2-3 days.

LabSmith uTE thermal electric modules for microfluidic temperature control

Temperature Sensor

LabSmith uTS-series temperature sensors.  The uTS can be used alone for on-chip or in-fluid temperature monitoring, or with the uTE-series thermal-electric module for complete temperature control. Controlled using the LabSmith uProcess software suite, the uTS and uTE precision thermal management products are a perfect complement to LabSmith's complete monitoring and control of microfluidic systems.

Temperature range: -150 – 200° C
Sensor type: K-type thermocouple
Accuracy: 0.5° C
Precision: 0.001° C

Part Number Wire Gauge Tip Insulation Tip Diameter Length
uTS01-STD-20 36 none 0.3-0.4 mm 20 cm
uTS01-STD-60 36 none 0.3-0.4 mm 60 cm

Contact LabSmith for custom length options.

The uPS-series pressure sensor requires a 4AM01 sensor manifold and EIB200 uProcess interface

Typically ships within 2-3 days.

LabSmith uProcess microfluidic automation temperature sensor

CapTite MV303 Manual 6-Port Injection Valve

6-port, 2-position manual valve. Three simultaneous flow streams between adjacent ports. Available for use with 360um capillary via one-piece fittings (not included). Can be mounted to LabSmith breadboards.

MV303 valves are constructed with Vespel® as the wetted material. Select valves are available with PCTFE as the wetted material. Contact LabSmith for pricing and availability.

Microfluidic Valve, MV303 manual six-port injector valve, CapTite

uProcess Automated 6-port Injection Valve AV303

Six-port, two position automated injection valve. Provides three simultaneous fluid paths. Available for interface with 360um capillary or 1/32" tubing.

The AV303 selector valve is the newest component of LabSmith’s uProcess platform, which simplifies construction and control of microfluidic systems. Automated uProcess components include syringe pumps, temperature and pressure sensors, selector valves, temperature controllers and more. Microsoft Windows®-based uProcess software provides straightforward control of all devices. With uProcess users can generate automated scripts to control both simple setups or complex lab automation.

LabSmith’s AV303 valves are constructed with Vespel® as the wetted material*, for use with a wide variety of chemicals.

Requires a 4VM02 valve manifold and EIB200 interface controller for communicating with PC. Connects to capillary via CapTite one-piece fitting (not included).

Also available as a manual valve.

* Selected valves are available with PCTFE Kel-F® as the wetted material. Contact LabSmith for pricing and availability.

Microfluidic Valve - uProcess microfluidic automated 6-port injection valve AV303-C360

CapTite MV202 Manual 4-Port Selector Valve

4-port, 2-position (+ closed) manual valve. Two simultaneous flow streams between adjacent ports.

LabSmith’s MV202 valves are constructed with Vespel® as the wetted material. Select valves are available with PCTFE as the wetted material. Contact LabSmith for pricing and availability.

Available for use with 360µm capillary or 1/32" tubing via one-piece fittings (not included). Can be mounted to LabSmith breadboards.

Microfluidic Valve, MV202-C360 manual four-port selector valve, CapTite

uProcess Automation Interface EIB200

uProcess interface with USB communication. Controls over 100 uDevices for sequential operation and up to 10 uDevices for simultaneous operation. Includes uProcess software, power supply, micro USB 2.0 cable, and flat ribbon connection cable. Compatible with uProcess Software versions 1.24.4 and later.

microfluidic automation, EIB200 uprocess automation interface

Flat Flex Ribbon Cables

Flat Flex Ribbon Cables.  For connection between 4VM-Valves or 4AM-Sensors. Part of the uProcess microfluidic fluid control and connection platform.  Note: each 4AM Analog Sensor Manifold or 4VM Valve Manifold comes with a set of 4 flat flex ribbon cables.



Flat Flex Ribbon Cables.  For connection between microfluidic automation valves and 4VM valve manifold, and microfluidic sensors and 4AM sensor manifold. Part of the uProcess microfluidic automation platform.

Breadboard Electrode Clips

Pack of 4 electrode clips for mounting up to 8 electrode cables (HVC high voltage cables or any 0.125" diameter cables) on a microfluidic breadboard. P/N: BB-ECLIPS



Use breadboard electrode clips (BB-ECLIPS08) to secure HVC high voltage cables from the HVS448 High Voltage Sequencer to a fluidic breadboard for secure application of electric fields to reservoirs or microfluidic chips.

breadboard electrode clips, bb-eclips

Chip Clamps

Set of 4. Use the BB-Chip Clamps to secure the microfluidic chip to the integrated breadboard (iBB) or LS-600-CH breadboard. P/N: BB-Chip_Clamps

Microfluidic chip clamp secures microfluidic chip to breadboard

Breadboard With Cut-Out for Microscope Imaging

4" x 6" breadboard for mounting CapTite microfluidic components. Includes a 1" x 3" cutout for mounting and viewing a slide or microfluidic chip with the SVM340 Microscope. Mounts to SVM340 breadboard sample stage (A-SVM-STAGE-BB).

Quantity Discounts

10–49 pieces: 12%
50–100 pieces: 25%
Contact LabSmith for quantities > 100.
Prices shown are list prices, Quantity discounts will be applied in shopping cart.

Microfluidics breadboard with cutout for microscope imaging LS-600-CH

Microscope Top Stage for Use with LabSmith Breadboards

Sample stage for coupling LabSmith breadboards (iBB or LS600-CH) with the SVM340 microscope.

Removable top stage for integrating microfluidic breadboards (LS-600-CH or iBB) SVM340 microscope

Stainless Steel Sample Plate

Stainless steel sample stage for the SVM340 Microscope with two rectangular openings: 14 x 75 mm and 21 x 66 mm. for use with the SVM340 standard stage [A-SVM-STAGE]

Stainless Steel Sample Plate (A-SVM-PLATE2) for use with SVY340 Video Microscope

Pressure Sensor

LabSmith uPS-series pressure sensors. The uPS can be installed in any LabSmith CapTite™ fitting and is ideal for accurate, low-dead volume pressure monitoring and control of microfluidic systems.  The uPS-series pressure sensors are controlled using LabSmith's uProcess software package.

Part Number Pressure Range Port Compatibility Accuracy
uPS0250-C360-10 0 - 250 kPa abs. 360 um or 1/32" CapTite™ ports 1%
uPS0250-T116-10 0 - 250 kPa abs. 1/16" CapTite™ ports 1%
uPS0800-C360-10 0 - 800 kPa abs. 360 um or 1/32" CapTite™ ports 1%
uPS0800-T116-10 0 - 800 kPa abs. 1/16" CapTite™ ports 1%

The uPS-series pressure sensor requires a 4AM01 sensor manifold and EIB200 uProcess interface.

uPS sensors typically ship within 2-3 days.

uProcess microfluidic automation Pressure Sensor uPS0800-T116-10

Analog Sensor Manifold

Analog sensor manifold for controlling up to 4 uPS pressure sensors and/or uTS temperature sensors using the LabSmith uProcess software. Includes 4 flat flex ribbon cables (1 x 8", 2 x 10", 1 x 12").

Typically ships within 2-3 days.

uProcess microfluidic automation sensor manifold 4AM01

Luer Lock Disposable Syringe

Luer Lock Disposable Syringe. Interfaces with C360-300, T132-300, and T116-300 Luer-Lock adapters. Volume: 12 ml. P/N: LS-SYRINGE_LL

luer lock, luer-lok, luer lock disposable syringe

LS-SCREWS .50: Interconnect Mounting Screw and Standoff Set

Set of 10 thread-forming screws (2-28 x 1/2”) and 10 standoffs to mount 5 interconnects to breadboard.

mounting screws, interconnect mounting screw and standoff set, LS-SCREWS .50

LS-SCREWS .25: Valve/Reservoir Mounting Screw Set

Set of 20 thread-forming screws (2-28 x 1/4”) to mount 10 valves or reservoirs to breadboard.

mounting screws, valve and reservoir mounting screw set, LS-SCREWS .25

Cross-channel Chip

Type: Cross Channel.

Design: Fluidic 106.

Fluid Interface: CapTite C360

Material: PMMA.

Cross-channel chip with direct connection to LabSmith's CapTite one-piece fittings (C360-100) and chip reservoirs (C360-405R).

Channel dimensions: 75 mm wide x 75 mm deep x 87 mm long.

Chip dimensions: 95.5 mm x 16 mm x 1.5 mm.

Lid Thickness: 175 mm.

See more CapTite microfluidic connector products.

Microfluidic Chip -Cross-channel CapTite Microfluidic Chip (P/N 10000178)

10um Mesh Polyester Filters, 6mm diameter

Set of 4 polyester filters with 10um diameter holes for CapTite refillable cartridges or uFilter-360 filter holder.

10 micron polyester mesh filter

uProcess Automated 4-port Selector Valve AV202

Two-position, four-port automated valve.  Available for interface with 360um (AV202-C360), 1/32" (AV202-T132), and 1/16” (AV202-T116) OD tubing.

The AV202 selector valve is part of LabSmith’s uProcess platform, which simplifies construction and control of microfluidic systems. Automated uProcess components include syringe pumps, temperature and pressure sensors, selector valves, temperature controllers and more. Microsoft Windows®-based uProcess software provides straightforward control of all devices. With uProcess users can generate automated scripts to control both simple setups or complex lab automation.




Constant flow example using the AV202 automated valve and other uProcess components.



LabSmith’s AV202 valves are constructed with Vespel® as the wetted material*, for use with a wide variety of chemicals.

Requires a 4VM02 valve manifold and EIB200 interface controller for communicating with PC.   Connects to capillary via CapTite one-piece fitting (not included).

Also available as a manual valve.

* Selected valves are available with PCTFE Kel-F® as the wetted material. Contact LabSmith for pricing and availability.

Microfluidic Valve - uProcess automated 4-port selector valve AV202

CapTite Union Adapter

Union adapter interconnect for connecting 360 µm OD and 1/32" OD tubing.  Two one-piece fittings required (one each of C360-100 and T132-100, not included).

Can be mounted to LabSmith breadboards.

Material: Ultem® or Acrylic (part number ending in 'A' is Acrylic).  Can be mounted to LabSmith breadboard.

Microfluidic interconnect - CapTite 360 micron to 1/32-inch tubing adapter- LabSmith

iBB-Tools

Breadboard mounting hardware and tools. Includes TORX wrench, hex wrench, screws for mounting 10 valves or reservoirs and 5 interconnects to breadboard, plus 4 chip clips and 4 electrode clips for mounting chips and electrodes to one of the uProcess (uPB or iBB) breadboards or CapTite breadboards.

microfluidic breadboard, ibb breadboard,uprocess, tools

A-SVM-OBJ DIN Objective

Standard DIN objectives for use with the SVM340 Microscope optics module. Note: one objective comes standard with your SVM340.

Power Numerical Aperture Working Distance [mm] Focal Length [mm] Field of View [mm]
4X 0.10 15.97 31.0 1.5 x 1.5
10X 0.25 6.3 16.76 0.6 x 0.6
20X 0.40 3.3 8.55 0.3 x 0.3
10X DIN objective for SVM Inverted Fluorescence Video Microscope

1/8″ OD Silicone Tubing

1/16" ID. 1/8" OD High-purity white Silicone Rubber Tubing, 1m length.

Microfluidic tubing - 1/8" OD silicone tubing

Luer Tip Disposable Syringe

Interfaces with chip reservoir or microfluidic ChipShop Luer interface chips.

Volume: 1ml. Fluidic interface: Luer.

P/N: LS-SYRINGE_LT

Luer Tip Disposable Syringe

CapTite Chip Reservoir

Threads into Bonded Port Connector to provide fluid reservoir. Also interfaces with Luer Tip Syringe for low pressure connection to syringe.

P/N: C360-405R.

Volume: 85µl.

Material: PEEK™.



Microfluidics - LabSmith CapTite Chip Reservoirs shown mounted to bonded port connectors (C360-400) on a chip.

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 157.

Fluidic interface: Luer.

Material: PMMA.

Straight-channel chip with 8-parallel channels.

Channel dimensions: 100 µm wide x 100 µm deep x 18 mm long.

Straight Channel Chip

Type: Straight Channel.

Design: Fluidic 156.

Fluidic interface: Mini Luer.

Material: Topas.

Description: straight channel chip with 4 parallel channels, channel dimensions: 200 µm wide x 200 µm deep x 58.5 mm long.

Lid thickness: 140 µm.

Microfluidics chip - Straight 4-channel Mini-Luer Chip (P/N 10000091)

Chip Interface Kit

The Chip Interface Kit includes all the CapTite™ fittings, ferrules, reservoirs and tubing you need to construct microfluidic circuits, as well as the chip-to-world interface components for leak-free connection to your microfluidic chips.

Kit prices offer you great value for chip-based research, including an overall 5% discount in addition to normal quantity discounts.

Chip Interface Kits are available for 360 micron capillary and 1/32-inch tubing.

Description 360 µm Kit 1/32" Kit Quantity
One-Piece Fittings C360-100 T132-100 25
One-Piece Plugs C360-101 C360-101 5
Bonded Port Connectors C360-400 T132-400 50
Chip Reservoirs C360-405R C360-405R 5
Luer-Lock Adapters C360-300 T132-300 4
Luer-Lock Disposable Syringe LS-SYRINGE_LL LS-SYRINGE_LL 4
Hex wrench LS-HEX LS-HEX 1
Epoxy Adhesive LS-EPOXY LS-EPOXY 1
PEEK capillary CAP360-150P TUBE132-010P 1 m

Typically ships within 1 week.

microfluidic chip interface kit

Capillary Interface Kit

The best value for CapTite fittings, including all the components needed for various applications. Prices include an overall 5% discount in addition to normal quantity discounts.

Description 360 µm Kit 1/32" Kit 1/16" Kit Quantity
Manual Valve MV201-C360 MV201-T132 MV201-T116 2
One-Piece Fittings C360-100 T132-100 T116-100 25
One-Piece Plugs C360-101 T132-101 T116-101 5
Tee C360-203 T132-203 T116-203 5
Cross C360-204 T132-204 T116-204 5
Luer-Lock Adapters C360-300 T132-300 T116-300 2
Luer-Lock Disposable Syringe LS-SYRINGE_LL LS-SYRINGE_LL LS-SYRINGE_LL 2
Breadboard LS-600 LS-600 LS-600 2
Breadboard Hardware & Tools BB-TOOLS BB-TOOLS BB-TOOLS 1
Capillary or Tubing CAP360-150P TUBE132-010P Tube116-030P 1 m
Microfluidics kit - capillary interface kit

Single User Kit

The Single User kit includes an excellent assortment of reusable microfluidic components to build manually controlled microfluidic systems.

This basic construction kit is the best value for CapTite fittings, offering an overall 5% discount in addition to normal quantity discounts. CapTite components are breadboard-based for quick assembly and feature low volumes, easy cleaning, and excellent durability.

Description 360 µm Kit 1/32" Kit 1/16" Kit Quantity
3-port, 2-position Manual Valve MV201-C360 MV201-T132 MV201-T116 2
One-piece Fitting C360-100 T132-100 T116-100 50
One-piece Plug C360-101 C360-101 T116-101 10
Tee Interconnect C360-203 T132-203 T116-203 5
Cross Interconnect C360-204 T132-204 T116-204 5
Bonded Port Connectors C360-400 T132-400 T116-400 25
Luer-Lock Adapters C360-300 T132-300 T116-300 2
Luer-Lock Disposable Syringe LS-SYRINGE_LL 2
Breadboard LS-600 2
Epoxy Adhesive LS-EPOXY 1
Breadboard Hardware & Tools BB-TOOLS 1
PEEK Capillary or Tubing CAP360-150P TUBE132-010P TUBE116-030P 1 m

Typically ships within 1 week.

microfluidic kit, single user microfluidics kit, components to experiment, prototype and educate in microfluidics

Needle Interconnect

Needle Y and Cross connectors. 27 gauge needle interconnects for low-pressure connection to 0.016" ID flexible tubing.

Material:  Ultem® (body) and 316 stainless steel needles.

Cross Connector (N27G-204-U) has four ports.

Y Connector (N27G-203Y-U) has three ports.



Microfluidic interconnect - CapTite Needle Connector

1/16″ OD Tubing

Tubing, 1/16" [1.59 mm] OD. 1m length. Choose from TUBE116-010P (250um ID PEEK), TUBE116-030P (750um ID PEEK), or TUBE116-030F (750um ID FEP) .

Microfluidic tubing, 1/16" OD Tubing, PEEK

1/32″ OD Tubing

PEEK Tubing. 1/32" [790 um] OD; 0.01" [250um] ID. 1m length. P/N: TUBE132-010P



Microfluidic Tubing, PEEK 1/32" OD tubing

360um OD Capillary Tubing

360um [0.014"] OD capillary tubing, 1 m length.

Available sizes and materials:

 Part Number

OD ID Material
CAP360-150P 360 um 150 um PEEK
CAP360-100S 360 um 100 um Fused Silica
CAP360-150S 360 um 150 um Fused Silica
CAP360-250S 360 um 250 um Fused Silica













NOTE: The fused silica capillary is externally coated with polyimide to provide abrasion resistance and maintain product strength.

To cut the PEEK capillary or tubing we recommend using a sharp blade such as a razor blade or X-Acto knife.

To cleave fused-silica capillary tubing with the ceramic cleaving stone (LS-CUTTER):

  • Place the capillary tubing on a clean, flat surface. If possible, apply slight linear tension to keep it taut.
  • Holding the cleaving stone at an approximate 30° angle to the tubing, draw the non-serrated edge of the cleaving stone across the tubing. Apply just enough pressure to penetrate the polyimide coating.
  • Pull the tubing axially until it breaks. If it won’t break, the polyimide coating has not been fully penetrated. Repeat the above steps, pressing down with slightly more force while drawing the cleaving stone across the tubing.
  • Once cleaved, inspect the end finish to ensure the cleave quality meets the application requirements.
360um capillary tubing

Capillary Cutting Stone

Cutting stone for cutting fused-silica capillary.

Note: the cutting stone will not cut PEEK capillary or tubing. For PEEK capillary or tubing, we recommend using a sharp blade.

Capillary tubing cutting stone

Epoxy Adhesive, 12ml

12ml two-part high-strength epoxy adhesive (3M™ DP420) for attaching bonded-port connectors to chip.

  • glass, metal and plastic bonding
  • room temperature cure
  • 20 minute work life, 2 hours set, 24 hours full strength
  • color: off-white
epoxy,microfluidic fittings

LS-TORX Driver

T7 TORX driver for installing breadboard screws.

LabSmith LS-TORX Torx driver (Torx wrench)

Hex Wrench, 1/8″

1/8" hex wrench for installing one-piece fittings and plugs.

hew wrench, 1/8" - LabSmith

CapTite Cartridge

Reusable column for customizable packing and easy sample preparation. Includes four 10µm polyester sample filters and two one-piece fittings.

Currently only available for 1/32" OD tubing. Contact LabSmith for special orders.

Available volumes: 50µl (uCTG-50-T132) and 150µl (uCTG-150-T132).

Material: PEEK™.

Microfluidic cartridge - LabSmith CapTite microfluidic cartridge

Standard Breadboard

4" x 6" platform for mounting CapTite microfluidic components. 0.25" hole spacing for mounting fluid circuit components. Suitable for all tubing sizes.
Secure components to breadboard using 2-28 self-tapping screws. Use 1/4" long screws to mount valves and breadboard reservoirs; 1/2" long screws for mounting interconnects.
LS-600-CH includes a 1" x 3" cutout for mounting and viewing a slide or microfluidic chip. Interfaces with LabSmith SVM340 breadboard stage. Chip clips, electrode clips, and breadboard mounting hardware sold separately.

Quantity Discounts

10–49 pieces: 12%
50–100 pieces: 25%
Contact LabSmith for quantities > 100.
Prices shown are list prices, Quantity discounts will be applied in shopping cart.

microfluidic breadboard, LS600

CapTite MV201 Manual 3-Port Selector Valve

3-port manual valve with "L" flow pattern. Available for use with 360µm capillary, 1/32" tubing, or 1/16" tubing via one-piece fittings (not included). Can be mounted to LabSmith breadboards.

MV201 valves are constructed with Vespel® as the wetted material. Select valves are available with PCTFE as the wetted material.  Contact LabSmith for pricing and availability.

Microfluidic Valve, microfluidic 3-port manual selector valve, 360 um capillary, 1/32" tubing, CapTite

CapTite Breadboard Reservoirs and Pressurized Vials

RESERVOIRS

Reusable PEEK™ reservoirs in two sizes. Reservoirs can be mounted to LabSmith breadboards.

BBRES-1ML 1.1 mL reservoir with sealable cap. Includes four ports for direct connection to capillary or tubing (three in reservoir and one in cap). Cap seals with Viton® o-ring (two included) for vacuum or pressure applications. Max pressure 1800 kPa (250 psi).  Four one-piece fittings or plugs required for each BBRES-1ML reservoir, not included.

BBRES-5ML 5 mL reservoir with push on Vinyl cap. Reservoir has three ports for direct connection to capillary or tubing. Not designed for pressure or vacuum applications. Three one-piece fittings or plugs required for each BBRES-5ML, not included.

Both reservoir sizes available for connection to 360µm OD (-C360), 1/32" OD (-T132), or 1/16" OD (-T116) tubing.



VIAL CAP ASSEMBLY

Reusable, sealable PEEK™ cap and vial. Max pressure 1800 kPa (250 PSI).

V-CAP 1.5 ml vial, conical base, clear polypropylene. Single hole cap. Available for connection to 360µm OD (-C360), 1/32" OD (-T132), or 1/16" OD (-T116) tubing. One one-piece fitting or plug required, not included.

Contact LabSmith for information on 2 and 3 port cap options.

microfluidic vial, vial cap, pressurized vial cap, V-CAP-C360-S, V-CAP-T132-S, V-CAP-T116-S





Microfluidic Breadboard Reservoirs - Captite

CapTite Filter Holder

Connector for holding a variety of filters including 3M™ Empore™ solid phase extraction filters (not included).

Two one-piece fittings required for connection to 360 um OD capillary (p/n C360-100, not included).

Material: PEEK™.

Microfluidic fittings, microfluidic filter holder, captite

CapTite Luer Lock Adapter Assembly

PEEK™ female fitting for connecting Luer Lock syringe to capillary or tubing. Available for use with 360µm OD tubing (C360-300A), 1/32" OD tubing (T132-300A), or 1/16" OD tubing (T116-300A).

Part numbers ending in 'A' include a one-piece fitting for attachment to tubing.

CapTite Microfluidic Luer-Lock Adapter

CapTite Bonded-Port Connector

Bonds to port on a through-hole chip. Compatible with ~1mm port size. Material: Ultem®.

C360-400 interfaces to 360µm OD capillary via C360-100 one-piece fitting (not included) or to chip reservoir.
C360-400S is a slim version of C360-400(2.8 mm diameter) for use in tight spaces.   Interfaces to 360µm capillary via C360-100 one-piece fitting (not included) or to chip reservoir.
T132-400 interfaces to 1/32" OD tubing via T132-100 one-piece fitting (not included) or to chip reservoir.
T116-400 interfaces to 1/16" OD tubing via T116-100 one-piece fitting (not included).

Bonded-Port Connector, CapTite, 360 um or 1/32" OD capillary, C360-400 or T132-400

CapTite Interconnect Y (Wye)

Multiport Y (wye) 3-port fitting for routing or combining microfluidic flows.

Available for use with 360µm OD capillary (C360-203Y), 1/32" OD tubing (T132-203Y), or 1/16" OD tubing (T116-203Y) via CapTite one-piece fittings (not included). Can be mounted to LabSmith breadboards.

Material: Ultem®.

Microfluidic connectors - LabSmith wye "y" microfluidic interconnect

CapTite Interconnect Elbow

Elbow interconnector for rerouting microfluidic flows. Available for use with:

  • 360µm OD capillary (C360-205 or C360-205A)
  • 1/32" OD tubing (T132-205 or T132-205A), or
  • 1/16" OD tubing (T116-205)

Two one-piece fittings required (not included) for connection to tubing or capillary. Material: Ultem® or Acrylic (part numbers ending in 'A' are Acrylic). Can be mounted to LabSmith breadboards.

Microfluidic interconnect-  Captite elbow interconnect

CapTite Interconnect Cross

Multiport fitting for routing or combining microfluidic flows.

Available for use with 360µm OD capillary (C360-204 or C360-204A), 1/32" OD tubing (T132-204 or T132-204A), or 1/16" OD tubing (T116-204).

Requires four CapTite one-piece fittings (not included) for connection to capillary or tubing. Material: Ultem® or Acrylic (part numbers ending in 'A' are Acrylic). Can be mounted to LabSmith breadboards.

Microfluidic interconnects - cross interconnect, 360 um capillary, 1/32" tubing, 1/16" tubing

CapTite Interconnect Tee

Multiport fitting for routing or combining microfluidic flows.

Available for use with 360µm OD capillary (C360-203/A), 1/32" OD tubing (T132-203/A), or 1/16" OD tubing (T116-203).

Requires three CapTite one-piece fittings (not included) for connection to capillary or tubing. Material: Ultem® or Acrylic (part numbers ending in 'A' are Acrylic). Can be mounted to LabSmith breadboards.

Microfluidic interconnect- CapTite tee interconnect

CapTite Interconnect Union

Union for connecting microfluidic tubing.

Available for use with 360µm OD capillary (C360-202/A), 1/32" OD tubing (T132-202/A), or 1/16" OD tubing (T116-202) via two CapTite one-piece fittings (not included).

Material: Ultem® or Acrylic (part numbers ending in 'A' are Acrylic). Can be mounted to LabSmith breadboards.

Microfluidic interconnect - LabSmith CapTite union interconnect

CapTite Two-Piece Adapter

For adapting a CapTite™ component to a different microfluidic tubing size.

Material: PEEK™

T116-A360: used to attach 360µm OD capillary to a component with a T116 female port.
T116-A132: used to attach 1/32" OD tubing to a component with a T116 female port.
T132-A360: used to attach 360µm OD capillary to a component with a T132 female port.
C360-A116: used to attach 1/16" OD tubing to a component with a C360 or T132 female port.
C360-A132: used to attach 1/32" OD tubing to a component with a C360 female port.

Microfluidic connector, LabSmith CapTite microfluidic adapter, 360 micron capillary, 1/32" tubing and 1/16" tubing

CapTite One-Piece Plug

One-Piece plug for plugging ports of CapTite microfluidic connectors and uProcess microfluidic automation components.

C360-101 plug can be used in any -C360 or -T132 port.  T116-101 plug can be used in any -T116 port.

Material: PEEK™.

CapTite microfluidic plug fitting - 360um capillary, 1/32" tubing

CapTite One-Piece Fitting (Ferrule)

One-Piece fittings (one-piece ferrules) provide fast, leak-free connections between capillary/tubing and CapTite™ microfluidic routing components. PEEK™.

Available for 360 µm OD capillary (C360-100), 1/32" OD tubing (T132-100), and 1/16" OD tubing (T116-100).

CapTite microfluidic one-piece fitting - 360 micron capillary, 1/32" tubing, 1/16" tubing

uProcess Plus Kit

The uProcess™ Plus kit offers everything in the uProcess Standard Kit plus much more. It's the most economical way to get everything you need to set up your microfluidic laboratory, including uProcess automated pumps, valves and sensors, CapTite ferrules and fittings, and capillary or tubing.

uProcess Plus kits offer 10% discount off individual component prices.

Description Qty LP-C360-KIT

for 360µm Capillary

LP-T132-KIT

for 1/32" Tubing

LP-T116-KIT

for 1/16" Tubing

Electronic interface controller with uProcess software 1 EIB200 EIB200 EIB200
Two-position automated valve 2 AV201-C360 AV201-T132 AV201-T116
Manifold for control of up to 4 automatic valves 1 4VM02  4VM02 4VM02
SPS01 syringe pump body 2 SPS01  SPS01 SPS01
Syringe glass and plunger set, specify size 3

SG-004-C360

SG-020-C360

SG-080-C360

SG-020-T132

SG-080-T132

SG-080-T116
Tool set for changing syringe glass/plunger 1 SPS-TOOLS SPS-TOOLS SPS-TOOLS
Manifold for control of up to 4 pressure or temperature sensors 1 4AM01 4AM01 4AM01
Pressure sensors, specify range(s) 2

uPS0800-C360-10

uPS0250-C360-10

uPS0800-C360-10

uPS0250-C360-10

uPS0800-T116-10

uPS0250-T116-10

Temperature sensor 2 uTS-STD-20 uTS-STD-20 uTS-STD-20
uTE Thermal-Electric Peltier Module, specify size(s).

Includes heat sink and conductive tape.

2

uTE02-040808

uTE02-132020

uTE02-040808

uTE02-132020

uTE02-040808

uTE02-132020

4 Channel Power Manifold 1 4PM01 4PM01 4PM01
Integrated uProcess breadboard with 8 device connectors and chip viewing port 1 iBB  iBB iBB
Mounting hardware set for iBB 1 iBB-TOOLS iBB-TOOLS  iBB-TOOLS
One-piece fitting 40 C360-100 T132-100  T116-100
One-piece plug 10 C360-101 C360-101  T116-101
1ML Breadboard reservoir 2 BBRES-C360-1ML BBRES-T132-1ML BBRES-T116-1ML
5ML Breadboard reservoir  2 BBRES-C360-5ML BBRES-T132-5ML BBRES-T116-5ML
Luer lock adapter 2 C360-300 T132-300 T116-300
Tee interconnect 5 C360-203 T132-203 T116-203
Cross interconnect 5 C360-204 T132-204 T116-204
Chip reservoir  5 C360-405R C360-405R not included
Bonded port connector 16 C360-400 T132-400 T116-400
Bonded port epoxy 1 LS-EPOXY LS-EPOXY LS-EPOXY
On-Chip Reservoir/female Luer taper connector 4 C360-450R C360-450R C360-450R
12mL disposable syringe, male Luer lock connector 2 LS-SYRINGE_LL LS-SYRINGE_LL LS-SYRINGE_LL
1mL disposable syringe, male Luer taper connector 2 LS-SYRINGE_LT LS-SYRINGE_LT LS-SYRINGE_LT
Microfluidic ChipShop chip: cross with 75um x 75um channels, PMMA, CapTite interface 2 10000178 10001802 10001802
PEEK capillary or tubing (meters) 2 CAP360-150P  TUBE132-010P TUBE116-030P

Typically ships within 1 week.

Microfluidics Kit - uProcess Plus kit for uProcess microfluidics automation

uProcess Standard Kit

uProcess™ kits are a convenient and economical package for setting up your microfluidic laboratory, including uProcess automated pumps, valves and sensors, CapTite ferrules and fittings, and capillary or tubing.

uProcess standard kits include 10% discount off of individual component pricing.

Description Qty

uProcess-C360-KIT

for 360µm Capillary

uProcess-T132-KIT

for 1/32" Tubing

uProcess-T116-KIT

for 1/16" Tubing

Electronic interface controller with uProcess software 1 EIB200 EIB200 EIB200
Two-position automated valve 2 AV201-C360 AV201-T132 AV201-T116
Manifold for control of up to 4 automatic valves 1 4VM02 4VM02 4VM02
SPS01 syringe pump body 2 SPS01 SPS01 SPS01
Syringe glass and plunger set, specify size 3

SG-004-C360

SG-020-C360

SG-080-C360

SG-020-T132

SG-080-T132

SG-080-T116
Manifold for control of up to 4 pressure or temperature sensors 1 4AM01 4AM01  4AM01
Pressure sensor, specify range(s) 2

uPS0800-C360-10

uPS0250-C360-10

uPS0800-C360-10

uPS0250-C360-10

uPS0800-T116-10

uPS0250-T116-10

Temperature sensor 2 uTS-STD-20 uTS-STD-20 uTS-STD-20
uTE Thermal-Electric Peltier Module, specify size(s)
Includes heat sink and conductive tape.
2

uTE02-040808

uTE02-132030

uTE02-040808

uTE02-132030

uTE02-040808

uTE02-132030

4 Channel Power Manifold  1 4PM01 4PM01 4PM01
Tool set for changing syringe glass/plunger 1 SPS-TOOLS SPS-TOOLS SPS-TOOLS
uProcess breadboard with 8 device connections 1 uPB-08 uPB-08 uPB-08
Mounting hardware set for uPB 1 BB-TOOLS BB-TOOLS BB-TOOLS
One-Piece fitting 25 C360-100 T132-100 T116-100
One-piece plug 5 C360-101 C360-101 T116-101
1 ML Breadboard reservoir  2 BBRES-C360-1ML BBRES-T132-1ML BBRES-T116-1ML
5 ML Breadboard reservoir  2 BBRES-C360-5ML BBRES-T132-5ML BBREs-T116-5ML
Tee interconnect 2 C360-203 T132-203 T116-203
Cross interconnect 2 C360-204 T132-204 T116-204
PEEK capillary or tubing (meters) 2 CAP360-150P TUBE132-010P TUBE116-030P

Typically ships within 1 week.

Microfluidics kit - uProcess Standard Kit for uProcess Automation

SPS-TOOLS Syringe/Plunger Installation Tools

Syringe/plunger installation tools for SPS01 automated syringe pump. Includes hex tool for syringe plunger removal/installation and hex wrench to secure syringe glass.

microfluidic syringe pump, sps01, syringe pump tools, uprocess

Syringe Glass & Plunger Set SG

Syringe glass and plunger set for use in the SPS01 programmable syringe pump.  Connects to capillary or tubing using via one-piece fitting (not included).

Part Number Volume Tubing Compatibility
SG-004-C360 5 ul 360 um OD via C360-100
SG-008-C360 10 ul 360 um OD via C360-100
SG-020-C360 20 ul 360 um OD via C360-100
SG-040-C360 50 ul 360 um OD via C360-100
SG-080-C360 100 ul 360 um OD via C360-100
SG-020-T132 20 ul 1/32" OD via T132-100
SG-080-T132 100 ul 1/32" OD via T132-100
SG-020-T116 20 ul 1/16" OD via T116-100
SG-080-T116 100 ul 1/16" OD via T116-100

Typically ships within 2-3 days

microfluidic syringe, syring glass and syringe plunger set

uProcess Syringe Pump SPS01

SPS01 syringe pump enables automated, coordinated dispensing of microfluidic volumes. Includes 1 syringe glass and plunger set. Requires an EIB200 interface controller for communicating with PC. Connects to capillary or tubing via CapTite one-piece fitting (not included). Syringe/plunger assembly tools required for removing syringe glass/plunger for cleaning.



Part Number Volume Tubing Compatibility
SPS01-004-C360 5 µl 360 µm OD via C360-100
SPS01-008-C360 10 µl 360 µm OD via C360-100
SPS01-020-C360 20 µl 360 µm OD via C360-100
SPS01-040-C360 50 µl 360 µm OD via C360-100
SPS01-080-C360 100 µl 360 µm OD via C360-100
SPS01-020-T132 20 µl 1/32" OD via T132-100
SPS01-080-T132 100 µl 1/32" OD via T132-100
SPS01-020-T116 20 µl 1/16" OD via T116-100
SPS01-080-T116 100 µl 1/16" OD via T116-100

Typically ships within 2-3 days.

syringe pump,microfluidic syringe pump, automated syringe pump, sps01

uProcess Automated 3-port Selector Valve AV201

Two-position, three-port automated valves.  Available for 360um capillary (AV201-C360), 1/32" tubing (AV201-T132), or 1/16" tubing (AV201-T116).

The AV201 selector valve is the newest component of LabSmith’s uProcess platform, which simplifies construction and control of microfluidic systems. Automated uProcess components include syringe pumps, temperature and pressure sensors, selector valves, temperature controllers and more. Microsoft Windows®-based uProcess software provides straightforward control of all devices. With uProcess users can generate automated scripts to control both simple setups and complex lab automation.


Sample switching circuit using AV201 automated microfluidic valve and other uProcess components.

LabSmith’s AV201 valves are constructed with Vespel® as the wetted material*, for use with a wide variety of chemicals.

Requires a 4VM02 Valve Manifold and EIB200 interface controller for communicating with PC.  Connects to capillary or tubing via one-piece fitting (not included). Also available as a manual valve.

Typically ships in 2-3 days.

* Selected valves are available with PCTFE Kel-F® as the wetted material. Contact LabSmith for pricing and availability.

Microfluidic Valve - uProcess automated microfluidic 3-port valve AV201

Breadboard Mounting Tools

Breadboard mounting hardware and tools. Includes a Torx driver, hex wrench, and screws for mounting 10 valves/reservoirs and 5 interconnects to breadboard.

microfluidic breadboard tools, BB-TOOLS

uProcess Breadboards

uPB breadboards are an optional platform for mounting uProcess automation products and CapTite microfluidic components, including  AV-Series automated valves, MV-Series manual valves, BBRES breadboard reservoirs, and CapTite Interconnects.

uProcess devices that interface with uProcess breadboard connectors include: EIB200 Automation Interface, SPS01 Syringe Pump, 4VM02 Valve Manifold, 4AM01 Sensor Manifold, 4PM01 Power Manifold, and uEP01 Electrophoresis Power Module.

uPB breadboards are available with 5, 8, or 12 device connections:

  • uPB-05: uProcess breadboard with 5 uDevice connections. Overall size: 5.25" x 7.25"; 0.25" hole spacing.
  • uPB-08: uProcess breadboard with 8 device connections. Overall size: 9" x 10"; 0.25" hole spacing.
  • uPB-12: uProcess breadboard with 12 device connections. Overall size: 12" x 12"; 0.25" hole spacing.
  • uPB-iBB: uProcess breadboard with 8 device connections and 1" x 3" cutout for chip viewing via LabSmith SVM340 microscope. Overall size: 12" x 12"; 0.25" hole spacing. (Custom size/shape cutouts available, please contact LabSmith for pricing).
Breadboard - uProcess uPB-iB8 Breadboard

LabPackage Microfluidic – Nanofluidic Work Station

Microfluidics and Nanofluidics approaches assist researchers in the life sciences, nanotechnology, chemistry and engineering. In these experiments it is essential to have total control of fluid flow and electric fields, and reliable capture and imaging of often transient phenomena.

LabSmith’s LabPackage gives you complete experiment control, helping you to get started with micro/nanofluidics experimentation quickly. LabPackage lets you take your lab from macro to micro/nano in a flash.

The LabPackage offers a 10% discount off individual pricing for all components. It is an impressively economical and convenient way to equip your entire laboratory!

NOTE: After you've placed your order, LabSmith will contact you to select the additional options.

Description Part Number Quantity
High Voltage Control
HVS448 Eight-channel high-voltage sequencer Option A HVS448-3000 or HVS448-3000-LC
Option B HVS448-6000D or HVS448-6000D-LC
Option C HVS448-8000D or HVS448-8000D-LC
1
High-voltage cable kit set (includes 8 cables) A-HVC8-STD 1
Micro-clip set for use with high-voltage cable kit (includes 8 clips) A-MC8-01 1
Platinum electrode wire, 0.584 mm dia (23 gauge), 10 cm length A-PT-ELECTRODE 1
USB-RS232 Adapter A-RS232-USB  1
Visualization
Synchronous video microscope. Includes control and acquisition software, A-SVM DP5-BW digital optics module, LED-B illuminator module, 10X objective, and motorized X-Y focus traverse stage, sample stage and plate. SVM340-DP5-BW 1
Schott filter for use in camera module.
Wavelengths available: 495, 515, 530, 550, 570, 590, 610, 630, 645, 665 nm.
A-FILTER-[WL] 1
Stainless steel sample stage for SVM340 with two rectangular openings:
20 x 32 mm and 22 x 66 mm.
A-SVM-PLATE2 1
USB-RS232 Adapter A-RS232-USB 1
Automated Fluid Control and Routing Specified for 360um capillary components. Contact LabSmith for 1/32" or 1/16" component options.
Electronic Interface Controller, includes uProcess™ software EIB200 1
Two-Position Automated Valve AV201-360 2
4 Valve Electronic Manifold 4VM02 1
Syringe Pump Body SPS01 2
Syringe glass and plunger - specify size for three (3) SG-004-C360
SG-020-C360
SG-080-C360
3
Pressure sensor - specify models for two (2) uPS0250-C360-10
uPS0800-C360-10
2
Temperature sensor uTS01-STD-20 2
Manifold for control of up to 4 pressure or temperature sensors 4AM01 1
uTE Thermal-Electric Peltier Module, specify size(s).  Includes heat sink and conductive tape. uTE02-040808

uTE02-132020

2
4 channel power manifold 4PM01 1
Integrated breadboard with 8 device connections and 1" x 3" cutout for chip viewing via SVM340. Includes mounting hardware for attachment to SVM340. iBB 1
1ML Breadboard reservoir BBRES-C360-1ML 2
5ML Breadboard reservoir BBRES-C360-5ML 2
Microfluidic ChipShop cross channel chip, 75 µm x 75µm , 87 mm, PMMA 10000178 2
One-Piece Fitting C360-100 75
One-Piece Plug C360-101 10
Tee C360-203 5
Cross C360-204 5
Bonded Port Connector C360-400 16
Chip Reservoir C360-405R 5
Luer-Lock Adapter C360-300 2
Breadboard mounting hardware and tools. Includes TORX wrench, hex wrench, and screws for mounting 5 valves, 10 interconnects to breadboard plus 4 chip clips and 8 electrode clips for mounting chips and electrodes to the iBB iBB-TOOLS 1
Tools for changing syringe glass and plunger set SPS-TOOLS 1
Epoxy Adhesive LS-EPOXY 1
Luer lock disposable syringe LS-SYRINGE_LL 2
Luer tip disposable syringe LS-SYRINGE_LT 2
PEEK capillary or tubing TUBING 2m
Typically ships within 3-4 weeks
LabSmith LabPackage microfluidics workstation. High voltage control, inverted fluorescence microscope, microfluidic automated valves, syringe pumps, sensors, and thermal components, and CapTite microfluidic connectors, fittings and ferrules.

A-SHIELD Light Shield

Light shield; sits on top of the SVM340 Microscope to block ambient light. Inside dimensions: 18 cm x 15 cm x 4 cm.

Light Shield (A-SHIELD) for use with SVM340 Inverted Fluorescence Microscopes

A-SVM-Stage Microscope Top Stage

Removable two-piece top mounting stage for the SVM340 Microscope. Includes Delrin top stage and stainless-steel sample plate.  Note: one microscope top stage is included with purchase of SVM340.

Stage Microscope Top Stage, A-SVM-Stage, SVM340 Inverted Fluorescence Microscope

Stainless Steel Sample Plate

Stainless steel sample stage for the SVM340 Microscope with one rectangular opening: 50 x75 mm.

Stainless Steel Sample Plate, A-SVM-Plate, SVM340 Synchronized Video Microscope

A-FILTER-KIT Schott Filter Kit

For use with the SVM340 Microscope. Kit includes 8 filters and 2 filter washers in wooden box.

Wavelengths: 475, 495, 515, 530, 550, 570, 590, 610.

Schott filter kit for LabSmith SVM340 Inverted Fluorescence Video Microscope

A-FILTER-[WL] Schott Filter

Schott filter for use in the SVM340 Microscope camera module. Includes one 12.5 mm diameter long pass filter and one filter washer.

Wavelengths available: 495, 515, 530, 550, 570, 590, 610, 630, 645, and 665 nm.

Schott filter 530nm for SVM Video Microscopes

A-RS232-USB

RS232-to-USB adapter.

rs-232 to usb adapter cable

A-ILLUM Four Channel Illuminator Module

This illuminator module for the SVM340 Microscope offers four selectable LED channels which can be used independently or simultaneously. You can specify the color for each channel from the following LED wavelengths:

  • Blue: 470 nm
  • Green: 527 nm
  • Yellow:590
  • Red: 625 nm
  • White

Contact LabSmith for UV illuminator module options. Note: The SVM340 base unit includes one illuminator module.

Illuminator - four channel illuminator for SVM340 Synchronized Video Microscope

SVM340 Synchronized Video Microscope

The SVM340 is a research-grade, inverted fluorescence video microscope for microfluidics and microbiology. The SVM340 microscope excels precisely where it counts: getting high-quality experimental data onto a hard drive. Extensive filter, camera, illumination and objectives options let you tailor the system for your research. Motorized traverse and focus, and software-configurable image-based "soft triggers" make the SVM340 perfect for µTAS prototypes and miniature process automation.

New Particle Counting Probes for the SVM340 let you count and characterize particles in real-time, at up to 5000 particles/frame. Characterize particles from sub-micron through hundreds of microns in diameter based on absorption, scattering, refraction or fluorescence. What's more, you can use the results to monitor and control your experiment as it happens. Applications include real-time sensor for microfluidic particle sorters and manipulators, step-and-scan culture characterization, powder particle size and shape quantitation, etc.

Base model includes one optics module (additional Optics Modules can be purchased separately):

  • 5 MP Black and White
  • 5 MP Color

Also included:

  • 10X DIN objective (4X and 20X objectives can be purchased separately)
  • Synchronous 4-channel illuminator
  • Bottom-up viewing and illumination
  • Motionless stage for unperturbed microsystems
  • Auto focus
  • Auto-acquisition with multiple triggering modes
  • Real time particle count and intensity measurement probes
  • Time lapse capability
  • Lossless recording to disk with post-save and instant replay
  • Particle Image Velocimetry probes

The SVM340 is compact (just 21 cm wide x 27 cm long x 9 cm tall) but scans up to 75 mm x 50 mm. With its small size, and costing thousands of dollars less than competing systems, the SVM340 is the ideal tool for micro-and nano-system research.

Typically ships within 4-5 weeks

SVM inverted fluorescence microscope with Particle Counting Probes

16 -Channel Experimental Timing Controller TT1680

LabSmith's TT1680 coordinates the timing and synchronization of the most demanding applications. With 16 inputs, 16 timing processors, two logic stages and eight outputs, the TT1680 outperforms a rack full of digital delay generators, gates, timers, filters and cables.

  • Complete toolkit for timing and triggering experiments
  • 16 channels of digital delays, timers, clocks and more
  • Sophisticated logic, gating and filtering
  • Windows- or LabView-based programming and operation
  • 10ns resolution and 100ps accuracy
  • Field-updatable software and firmware

The TT1680 consists of both ground-breaking software and a programmable hardware controller. Trigger experimental design software makes it easy to create sophisticated control schemes from a PC, with a built-in compiler that can accept C-style assignments and operations.

The TT1680 hardware controller can function as part of a computer-based control system using Trigger or LabView, or it can operate in stand-alone mode. With the TT1680 linked to your computer, you'll quickly program, refine and expand experiments. Using stand-alone mode, you can store and recall up to 64 complete settings, then trigger and monitor an experiment from the TT1680 front panel. You'll have the flexibility to design experiments offline, then to embed the controller in your test environment for set-and-forget operation.

With a single TT1680 you can synchronize all experimental hardware. Each of the sixteen logic channels can operate as a clock, digital delay, delayed trigger, counter, and more, all with 10 ns resolution and programmable trigger logic.

The TT1680 also brings you functions that are simply not available elsewhere. "Dynamic delay triggering" lets you reliably capture elusive phenomena, basing its delay time on a real-time measurement. This unique mode lets you control uncertain timing situations, such as synchronizing a flash to a passing projectile, or timing the spark in a cyclic combustion system. "False-Trigger Suppression" mode helps tame noisy signals and prevents unwanted triggering in sub-optimal environments. "Drift Compensation" mode offers automatic, closed loop timing compensation for maintaining extremely high laser accuracy, run after run.

The TT1680 goes far beyond the functions of a digital delay generator, pulse generator, logic delay or logic controller, integrating all of these functions and more in a single unit.



Typically ships within 1-2 weeks

TT1680 programmable experiment controller, experiment timing controller

2-Channel Experimental Timing Controller LC220

The two channel LC220 integrates and synchronizes complex physical experiments. Featuring logic-based triggering and timing modes unavailable in any other system, the LC220 is a smarter digital delay generator, for authoritative control over lasers and test apparatus.

The LC220 combines ground-breaking software with a compact, programmable hardware controller. The two-channel controller can be programmed from a PC, then operated in stand-alone mode for benchtop or embedded operation. Its outputs allow control over flash lamps and Q-switches, shutters, flow controllers, etc. External feedback to its inputs can be used to synchronize triggering of uncertain events, such as the motion of high-speed machinery.

  • Two channels function as digital delays, timers, clocks and more
  • 5 ns resolution and 100 ps accuracy
  • Unique logic, gating and filtering
  • Windows- or LabView-based programming and operation
  • Field-updatable software and firmware

LabSmith’s Trig220 experiment design software makes it easy to build simple or sophisticated control schemes. Each channel can operate as a traditional clock, digital delay, delayed trigger, or counter. Additional timing modes offer functionality not available in any other product, including Dynamic Delay for capturing elusive events, and Noise Suppression for reliable triggering in sub-optimal environments. Drift Compensation mode offers automatic, closed loop timing compensation for maintaining extremely high laser accuracy, run after run.

The LC220 provides unique control for applications in laser diagnostics, materials science, gas dynamics, combustion, radar simulation, and many other applications. Outperforming a rack-full of typical timing gear and available for under $2000, the LC220 represents an outstanding value for high-resolution laser-based research.



Typically ships within 2-3 weeks

LC220 programmable experiment controller

8-Channel Experimental Timing Controller LC880

LabSmith's LC880 Programmable Experiment Controller coordinates, integrates and synchronizes complicated physical experiments, simply and affordably. With 8 timing channels, logic integration, unique timing modes and 10 ns resolution, the LC880 outperforms a rack full of digital delay generators, gates, timers, filters and cables, all for the price of a single delay.

  • Complete toolkit for timing and triggering experiments
  • 8 channels of agile digital delays, timers, and clocks
  • Sophisticated logic, gating and filtering
  • Windows- or LabView-based programming and operation
  • 10ns resolution and 100ps accuracy
  • Field-updatable software and firmware

The hardware controller can function as part of a computer-based control system using Trigger or LabView, or it can operate in stand-alone mode. With the LC880 linked to your computer, you'll quickly program, refine and expand experiments. Using stand-alone mode, you can store and recall up to 64 complete settings, then trigger and monitor an experiment from the LC880 front panel.

In applications from gas dynamics to fracture mechanics, the LC880 earns its place among oscilloscopes and power supplies as an indispensable lab tool.

Typically ships within 1-2 weeks

LabSmith LC880 Programmable Experiment Controller

A-PT-Electrode

Platinum electrode wire, 0.584 mm dia (23 gauge), 10 cm length. Purity: 99.95%

Interfaces directly with HVC high-voltage cable terminals (for use with the HVS448 High Voltage Sequencer) or with the cables supplied with the uProcess uEP01-300 Electrophoresis Power Module.  Can be used with or without a Microclip connector.



platinum electrode

Micro Clip Set MC8

Set of 8 micro clips for grabbing electrodes. Interfaces directly with HVC high-voltage cable terminals for use with the HVS448 High Voltage Sequencer, or with the cables supplied with the uProcess™ uEP01-300 Electrophoresis Power Module.



microclips set of 8, MC1GY

HVC High Voltage Cables for HVS448

High-voltage cable kit for use with HVS High Voltage Sequencers. Three options are available:

  • A-HVC8-STD: High-voltage cable kit. Includes eight 1.25 m current-limiting cables with friction-fit terminals.
  • A-HVC8-LONG: High-voltage cable kit. Includes eight 2.25 m current-limiting cables with friction-fit terminals.
  • A-HVC8-Custom: High-voltage cable kit. Includes eight current-limiting cables with friction-fit terminals. Custom lengths up to 3.5 m.

Cable terminations can connect directly to 23-gauge electrode wire, or to an electrode via a micro clip.

high voltage cable set,hvs448 high voltage sequencer

HVS448 High Voltage Sequencers

The LabSmith HVS448 High Voltage Sequencer provides eight high-voltage channels with programmable sequencing for an entirely new level of high-voltage control. With innovative voltage supply, up to 8000V differential range, and voltage sensing, current supply, current sensing, and a ground-breaking sequencing environment, the HVS448 integrates your entire experiment, simply and safely.

  • Eight channels supplying/sensing up to ±4.0kV/±6mA
  • 1 kHz sequencing for microfluidics and MEMS
  • 16-bit current sensing resolution
  • Ground-breaking Sequence Software for intuitive sequencing
  • Complete experiment control for microsystem analysis.

Applications include electrophoresis, dielectrophoresis, capillary electrophoresis, Capillary Electrochromatography (CEC), microfluidics, MEMS, lab-on-a-chip research and many more.

LabSmith HVS448 High Voltage Sequencer Models

Model Max Output Voltage [+V] Max Voltage Differential [V]
Max Output Current
Overall [+mA] Per Channel [+mA]
Monitor Resolution
Current [nA] Voltage [mV]
8000D 4000 8000 2.5 1.8 250 150
8000D-LC 4000 8000 0.72 0.09 13 150
6000D 3000 6000 3.2 2.4 300 100
6000D-LC 3000 6000 0.96 0.12 15 100
3000 3000 3000 6.0 4.8 300 100
3000-LC 3000 3000 1.9 0.24 15 100
3000D 1500 3000 6.0 4.8 500 50
3000D-LC 1500 3000 1.9 0.24 25 50
1500 1500 1500 12 10 500 50
1500-LC 1500 1500 4.0 0.50 25 50
800 800 800 25 20 1000 25
800-LC 800 800 8.0 1.0 50 25
400 400 400 50 40 2000 12

Typically ships within 1-2 weeks

LabSmith HVS448 High Voltage Sequencer

LabSmith • https://labsmith.com • +1-925-292-5161 • info@labsmith.com

Item added to cart.
0 items - $0.00
